22 mm 2 strip parquet battened flooring system

22 mm 2 strip parquet battened flooring system

Junckers Ltd

Battened flooring system featuring 129 mm wide boards manufactured from two rows of graded solid hardwood staves, dovetail jointed together.

Jump to:
+44 (0)1376 534700 www.junckers.co.uk
Description

Battened flooring system featuring 129 mm wide boards manufactured from two rows of graded solid hardwood staves, dovetail jointed together. The boards have precision machined tongued and grooved edges, which facilitate assembly and ensure square, secure joints.

Boards are supplied in a variety of hardwood species, to a controlled moisture content, and in boards 3700 mm long.

A range of batten types and sizes is available to suit individual requirements.

Designed for heavy wear and durability. Suitable for installation over underfloor heating (consult Junckers for special details), but should not be used in wet areas.

Available with a range of factory finishes which, if necessary, can be refinished using suitable cleaning agents, oils and lacquers. Renovation by in-situ precision sanding and refinishing is also possible.

Accreditations:

  • FSC.
  • PEFC.
  • World Squash Federation.
  • England Squash.
  • Badminton World Federation.
  • FIBA.

General information

Finish

Untreated

UV light cured lacquer plus Junckers polyurethane Isolacquer – Silk Matt

UV light cured lacquer plus Junckers polyurethane Isolacquer – Ultra Matt

Urethane Rustic oil

Material

Hardwood

WarrantyDescription

Labor: 25 year project specific where fitted by an approved contractor, Parts: 10 year project specific or 25 year where fitted by approved installer

Uniclass 2015

Ss_30_20_95_10 Battened wood floating floor systemsPrimary

CAWS

K21/130 Battened wood floating floor

Specification data - Battened wood floating floor systems

Product Reference

22 mm 2 strip battened flooring systems

Wood species

Ash

Beech

Black Oak

Driftwood Grey

European maple

Nordic ash

Nordic Oak

Nordic Sylvaket

Oak

Sylvacolor

SylvaKet

Sylvared

Appearance

Classic

Harmony

Variation

Finish

Untreated

UV light cured lacquer plus Junckers polyurethane Isolacquer – Silk Matt

UV light cured lacquer plus Junckers polyurethane Isolacquer – Ultra Matt

Urethane Rustic oil

Batten system

Junckers 45 x 36 mm high plain

Junckers 45 x 48 mm high plain

Junckers 45 x 22 mm high plain

Junckers BluBat 45 x 45 mm high foam backed

Junckers BluBat 45 x 57 mm high foam backed

Junckers BluBat 45 x 31 mm high foam backed

Junckers New Era Levelling System

Comprising batten, cradle, spacer and height extender.

Junckers New Era Acoustic Levelling System

Comprising batten, cradle, spacer and height extender.

Junckers UnoBat 45 System

Junckers UnoBat 62+ System

Junckers DuoBat 120+ System

Vapour control layer

Junckers SylvaThene

Accessories

None

Expansion strip

Nosing

Skirting

Stair nosing

Standard product features

Battens:

– Junckers Plain battens:

  • 45 x 22 mm high, 45 x 36 mm high, 45 x 48 mm high.
  • Designed to provide space for piping, cabling and other similar sized services.

– Junckers BluBat battens:

  • 45 x 31 mm high, 45 x 45 mm high and 45 x 57 mm high foam backed treated battens.
  • Designed for impact sound reduction, e.g. in multi-purpose halls.

– Junckers New Era System:

  • A polypropylene cradle system for uneven sub floors, comprising batten, cradle, spacer and height extender.

– Junckers Uno Bat 45 System:

  • High quality, 23 mm high, laminated spruce batten with an integrated rubber progressive shock absorption system.

– Junckers UnoBat 62+ System:

  • High quality, 28 mm high, laminated spruce batten system for uneven sub floors, with an intergrated rubber progressive shock absorption system.

–- Junckers DuoBat 120+ System:

  • High quality, double battened, laminated spruce batten system for uneven sub floors, with an intergrated rubber progressive shock absorption system.

Standard:

Conforms to EN 14904: 2006 category A3 or A4.

Method of fixing:

Secret nailed.

Digital objects
PlatformCompatibleVersionCertified to
IFC
IFC2X3 1 1.3
Revit
Revit 2016 3 2.0
Download now from NBS National BIM Library
