NBS Source

Application

Suitable for worktops, kitchen islands, splashbacks, upstands, vanity tops, bathrooms, bar counters, bar tops, serveries, reception desk, table top, furniture, desk top. Indoor or outdoor use.

Description

Porcelain surface suitable for use in residential and commercial projects.


Features and benefits:

  • Durable.
  • Scratch and stain resistant.
  • Extremely heat resistant.
  • Resistant to household chemicals, acids and solvents.
  • Mould and mildew resistant.
  • Non-porous and non-absorbent.
  • Suitable for a wide range of different design applications; consult manufacturer for details.
  • Low maintenance - no sealing or waxing required, suitable for cleaning with regular detergents.
  • Suitable for both indoor and outdoor use.

General information

Color

Black

Finish

Honed

Material

Porcelain

Shape

Rectangle

Length

3200 mm

Width

1600 mm

Height

12 mm

WarrantyDescription

Ten year

Commercial warranty.

Lifetime

Residential warranty.

Uniclass

Pr_40_30_30_96 WorktopsPrimary
Pr_40_30_30_18 Countertops
Pr_40_50_21_60 Office tables
Ss_40_25_20/510 Purpose made furniture
Pr_40_30_30_45 Kitchen splashbacks
Pr_40_20_76_95 Vanity and washroom furniture

CAWS

N11/370 Shelving

N10/145 Vanity and washroom furniture

N10/160 Shelving system

N10/125 Desks and tables

N12/320 Worktops

N10/10 Purpose-made

N10/30 Shelving system

N10/15 Desks and tables

N11/380 Purpose-made units

N10/110 Purpose-made

N12/440 Purpose made

N12/440 Purpose made

N12/320 Worktops

N10/200 Worktops

N11/340 Worktops

N11/20 Worktops

Specification data - Worktops

Material

Porcelain.

Dimensions

-

Plan size

1600 x 3200 mm.

Thickness

12 mm.

Exposed edges

-

Profile

Mitred.

Upstands

-

Finish

To match worktop.

Not applicable.

Height

Insert requirements or omit.

-

Cutouts

Insert requirements or omit.

-

Integral accessories

Insert requirements or omit.

-

Colour

130 Darma.

Black.

Finish

Honed.

Weight

150–160 kg.

Water absorption

To ASTM C373, ≤0.1%.

Density

To EN 10545-3, ≥2.3 gr/cm³.

Flexural strength

To EN 14617-2, > 50 MPa; to ASTM C880/M, > 35 MPa.

Impact resistance

To EN 10545-5, ≥ 0.85.

Breaking strength

To EN 10545-4, ≥ 5000 N.

Abrasion resistance

Deep abrasion resistance.

To EN 10545-6, ≤ 175 mm³.

Frost resistant and chemical resistant

Frost resistance.

To EN 10545-12, no defects observed.

Linear thermal expansion coefficient

To EN 14617-11/ASTM 372, ≤ 6.5 x 10-6 per °C-1.

ThermalConductivity

To EN 12664, 1.2 W/(m∙K).

Thermal shock resistance

To EN 10545-9, no damage observed.

Surface

Surface burning.

To ASTM E84, Class A - FSI: 0-25; SDI: 0-450.

Fire classification (to EN ISO 13501-1)

A2-s-1, d-0.

Fire performance

To AS 1530.3:1999, Ignitability Index (0-20), 0; Spread of Flame Index (0-10), 0; Heat Developed Index (0-10), 0; Smoke Developed Index (0-10), 0–1.

Stain Resistance

To EN 10545-14, Pass.

Chemical resistance class

To ASTM C650/ EN 10545-13, Class A.

Digital objects

Platform Compatible Version Certified to
IFC
-

1

2.1
Revit
-

1

2.1
Download now from NBS National BIM Library
