MechSlip Brick Cladding System - Technical Guide

System Properties System weight – 51.5kg/m2 Resistance to wind loading – 3.6kN/m2 Brick Properties Frost resistance – F2 Fire rating – A1 Typical Brick Dimensions Stretcher brick face dimensions – 215mm x 65mm Corner brick face dimensions – 102 x 215 x 65mm Brick thickness – 28mm Design Criteria Maximum vertical support centres – 600mm Maximum bracket centres – 600mm Middle rail length – 3000mm Top rail length – 3000mm Starter rail length – 3000mm Bracket adjustment range – 40mm-300mm Movement joints – Maximum 6m Building substrates – Masonry, Concrete, SFS
