Summary
Monolithic surface for ceilings and walls that provides outstanding acoustic comfort and fire safety.
Monolithic surface for ceilings and walls that provides outstanding acoustic comfort and fire safety.
Application
Suitable for ceilings and walls in new build or renovation projects. Applications include:
- Offices.
- Education.
- Leisure.
- Conservation and heritage
- Retail.
- Residential
Suitable for ceilings and walls in new build or renovation projects. Applications include:
- Offices.
- Education.
- Leisure.
- Conservation and heritage
- Retail.
- Residential
Description
Monolithic, acoustically rated system for ceilings and walls.
Features and benefits:
- The monolithic surface provides acoustic comfort and fire protection.
- Non-demountable.
- Comprised of a 40 mm stone wool panel, filler and render.
- Can be flat or curved, and direct or suspended installation.
- The white surface provides high light reflection and light diffusion, providing even light distribution and reducing the need for artificial light.
- A seamless system that allows for easy integration of all services and the possibility to repair the surface.
- Fully recyclable.
- Stone wool provides no sustenance to microorganisms (tested in accordance with JIS Z 2801: 2000 and ASTM C 1338-96).
- Dimensionally stable, even at humidity levels of up to 100% RH.
- Other configurations may be available – consult manufacturer for details.
- Achieves up to 60 minutes fire resistance in accordance with European test standards and national approvals. Contact manufacturer for fire resistance documentation.
- The surface can be vacuum cleaned with a soft brush attachment.
- The surface can be cleaned using a damp cloth or sponge with a slightly alkaline detergent (pH between 7 and 9) without alcohol, ammonia or chlorine. This may render the surface slightly shinier; manufacturer recommends cleaning the entire surface evenly.
- Rockfon acoustic solutions are Cradle to Cradle Certified® Bronze.
Monolithic, acoustically rated system for ceilings and walls.
Features and benefits:
- The monolithic surface provides acoustic comfort and fire protection.
- Non-demountable.
- Comprised of a 40 mm stone wool panel, filler and render.
- Can be flat or curved, and direct or suspended installation.
- The white surface provides high light reflection and light diffusion, providing even light distribution and reducing the need for artificial light.
- A seamless system that allows for easy integration of all services and the possibility to repair the surface.
- Fully recyclable.
- Stone wool provides no sustenance to microorganisms (tested in accordance with JIS Z 2801: 2000 and ASTM C 1338-96).
- Dimensionally stable, even at humidity levels of up to 100% RH.
- Other configurations may be available – consult manufacturer for details.
- Achieves up to 60 minutes fire resistance in accordance with European test standards and national approvals. Contact manufacturer for fire resistance documentation.
- The surface can be vacuum cleaned with a soft brush attachment.
- The surface can be cleaned using a damp cloth or sponge with a slightly alkaline detergent (pH between 7 and 9) without alcohol, ammonia or chlorine. This may render the surface slightly shinier; manufacturer recommends cleaning the entire surface evenly.
- Rockfon acoustic solutions are Cradle to Cradle Certified® Bronze.
Product certifications
Digital objects
Color
White
White
Finish
Smooth
Smooth
Material
Stone wool
Stone wool
Shape
Square, Rectangle
Square, Rectangle
Length
1200 mm
1200 mm
Width
1200 mm, 1800 mm
1200 mm, 1800 mm
Height
40 mm
40 mm
Warranty description
15 year
15 year
Specification
Classification data
System performance
Airborne sound absorption.
Airborne sound absorption.
Coating
-
-
Binding agent
Seamless acoustic render.
Seamless acoustic render.
Insulant
Stone wool.
Stone wool.
Protective membrane
High performance membrane with a mineral fleece.
High performance membrane with a mineral fleece.
Additional properties
Module size
1800 x 1200 x 40 mm.
1200 x 1200 x 40 mm.
Edge
TE Elegant Render.
TE Elegant Render.
Sound insulation
22 dB (Rw, to ISO 140-3).
22 dB (Rw, to ISO 140-3).
Reaction to fire
A2-s1, d0 (to EN 13501-1).
A2-s1, d0 (to EN 13501-1).
Noise reduction coefficient (NRC)
0.90.
0.90.
Sound absorption
Class A (to ISO 11654: 0.95 αw).
Class A (to ISO 11654: 0.95 αw).
Light reflectance
87%.
87%.
Certification
Cradle to Cradle Certified® Bronze.
Cradle to Cradle Certified® Bronze.
Sustainability data
Contains Red List materials
No
No
Country of product manufacture
Poland
Poland
A1–A3 ('Production stage')
Embodied carbon as defined in BS EN 15804
Normalized unit
5.38 kg CO₂ eq/kg
5.38 kg CO₂ eq/kg
Declared unit
5.38 kg CO₂ eq/kg
5.38 kg CO₂ eq/kg
Recyclability
100%
100%
