Summary
A high pressure laminate.
-
-
Application
Suitable for either horizontal, vertical, or postforming applications including:
- Desktops, tabletops
- Countertops
- Retail fixtures
- Curved decorative wall panels
- Wall cladding, feature walls
- Doors
- Cabinets and vanities
- Casework
Three standard grades of Pionite® and Nevamar® high-pressure laminate are suitable for most applications:
- General Purpose Type G48/NG48 is most often used in horizontal applications where high impact resistance and a durable, decorative surface is required.
- Postforming Type F39/NF39 is designed for manufacturing countertops and other horizontal surfaces where the laminate may be heated and rolled over the substrate edge to eliminate seams.
- Type F28/NF28 is designed for applications where impact resistance is less critical. Type F28/NF28 can also be postformed.
-
-
Description
A high-pressure laminate (HPL) manufactured under extreme pressure to deliver a decorative surface that is strong and durable, yet flexible and easy to fabricate. HPL is a versatile surface, making it a suitable choice for a range of interior horizontal and vertical applications where an attractive, yet resilient, surface solution is required.
Features and benefits:
- 500+ colours/patterns in both Pionite® and Nevamar® brands.
- 22 finish options.
-
-
Color
Beige, Black, Blue, Brown, Cream, Green, Grey, Ivory, Orange, Pink, Purple, Red, Turquoise, White, Yellow, Other
-
-
Finish
Smooth, Gloss, Grained, Textured, Matte, Embossed
-
-
Material
High pressure laminate (HPL)
-
-
Shape
Rectangle
-
-
Length
2438 mm, 3048 mm, 3658 mm
-
-
Width
914 mm, 1219 mm, 1524 mm
-
-
Height
0.7 mm, 1.0 mm, 1.2 mm
-
-
WarrantyDescription
One year
-
-
Specification
Classification data
Standard
To ISO 4586, NSF-International Standard 35, L-P-508H.
-
-
Classification
To NEMA LD3/ VGP.
-
-
Thickness
1.14 mm.
-
-
Finish
Aged Bark (AB)., Armored Protection (ARP) (T), Ashwood (AW)., Barnboard (BB)., Crystal (CR)., Evolution (EV)., Fineline (FL)., Gloss (GL)., Granite (GR)., Groovy (GV)., LineZ (LZ)., Medium Gloss (MG)., Natural Stone (NS)., Polished Velvet (PV)., Slate (SL)., Soft Leather (LR)., StoneX (SX)., Super Matte (SM)., Textured / Suede (SD)., Timberline (TL)., Velvet (VE)., Wood Essence (WE).
-
-
Execution
Install products in accordance with manufacturer’s instructions and approved submittals.
-
-
Additional properties
Appearance
To NEMA LD 3-2005, Complies.
-
-
Cleaning
To NEMA LD 3-2005, Cleanability: 7–10; Stain 1–10: No effect; Stain 1–15: No effect.
-
-
Wear resistance
To NEMA LD 3-2005, 1000 cycles.
-
-
SurfaceSpreadOfFlame
To ASTM E-84/UL723, 35.
-
-
Smoke generation
To ASTM E-84/UL723, 35.
-
-
Third-party certification
UL GREENGUARD.
-
-
