Anicius - Clay Facing Brick
Verified 9 months ago
Vandersanden Brick
WF
nbs-symbol
Add to spec
Anicius - Clay Facing Brick
Verified 9 months ago
Vandersanden Brick
DF
nbs-symbol
Add to spec
Summary
A dark brown brick with shades of white and light brown.
A dark brown brick with shades of white and light brown.
Color
Brown, Grey, White, Yellow
Brown, Grey, White, Yellow
Finish
Sanded-coated
Sanded-coated
Material
Clay
Clay
Shape
Rectangle
Rectangle
Size
210 x 100 x 50 mm, 215 x 100 x 65 mm
210 x 100 x 50 mm, 215 x 100 x 65 mm
Specification
Standard
To BS EN 771-1.
To BS EN 771-1.
Brick description
Facing brick.
Facing brick.
Appearance
Dark brown brick with shades of white and light brown, with a sanded-coated and grained structure.
Dark brown brick with shades of white and light brown, with a sanded-coated and grained structure.
Work size (length x width x height)
210 x 100 x 50 mm.
215 x 100 x 65 mm.
Tolerances
-
-
Mean value
T2.
T2.
Range
R1.
R1.
Compressive strength
-
-
Mean compressive strength (minimum)
≥20 N/mm².
≥20 N/mm².
Durability designation
F2.
F2.
Density
-
-
Gross dry
1630 kg/m³.
1630 kg/m³.
Net dry
1740 kg/m³.
1740 kg/m³.
Tolerance
D1.
D1.
Water absorption
≤14% m/md.
≤14% m/md.
Configuration
Frogged.
Frogged.
Thermal conductivity
≤0.60 W/m·K.
≤0.60 W/m·K.
Water vapour permeability
5/10 µ.
5/10 µ.
Reaction to fire
Class A1 to BS EN 13501-1.
Class A1 to BS EN 13501-1.
Additional properties
Active soluble salts
S2.
S2.
Jointing
Beige., Black/ Anthracite., Grey., Joint free., White.
Beige., Black/ Anthracite., Grey., Joint free., White.
Sustainability data
Country of product manufacture
Belgium
Belgium
