Summary
Acoustic louvres suitable for applications where both noise control and airflow are required; can be installed as standalone screens or integrated into building facades.
-
-
Application
Suitable for applications where both noise control and airflow are required, the louvres can be installed as standalone screens, or can be integrated into building facades. Applications include:
- Car parks, plant rooms, substations, cooling towers and any other application that requires both sound attenuation and ventilation.
- Areas where sound levels that escape from exterior or interior walls need to be minimized.
-
-
Description
Acoustic louvres suitable for applications where both noise control and airflow are required.
Features and benefits:
- Weighted sound reduction of 10–19 dB, depending on model. Chevron double bank designs offer maximum sound attenuation and are sight proof.
- Mineral wool infill material with acoustic, thermal and fire resistant properties. Water repellent to prevent moisture build up, damp and rot.
- Galvanized mesh on the back and underside of louvre blades maximizes noise reduction performance.
- Supplied as modules for ease of installation.
- Can be installed as standalone screens, or can be integrated into building facades.
- Can be used in conjunction with any Construction Specialties rain defence, ventilation or screening louvre systems, if required.
- Manufactured from galvanized mild steel as standard.
- Supplied unfinished as standard or can be polyester powder-coated to RAL Classic colours.
- A range of accessories, including blanking panels, bird/ vermin screens, insect mesh and louvred doors are available if required.
-
-
Color
Silver, Other
-
-
Finish
Painted, Unfinished
-
-
Material
Carbon steel, Mineral wool
-
-
Shape
Rectangle
-
-
Length
150 mm, 300 mm, 600 mm
-
-
Width
Bespoke
-
-
Height
Bespoke
-
-
Warranty description
Two year
-
-
Specification
Material
Galvanized steel with mineral wool infill.
-
-
Finish
Unfinished (galvanized)., Painted.
-
-
Colour
Silver., Other.
-
-
Construction
Supplied prefabricated as modules, complete with perimeter frame. Louvre blades with acoustic infill and galvanized mesh on back & underside.
-
-
Calculated weighted sound reduction index (Rw)
-
-
-
Standard
10 dB.
-
-
Frequency range
Manufacturer's standard.
-
-
Louvre configuration
-
-
-
Number of banks
One.
-
-
Blade orientation
Horizontal.
-
-
Blade pitch
150 mm.
-
-
Accessories
None., Bird/ vermin guard, galvanized steel welded mesh., Bird/ vermin guard, expanded aluminium welded mesh., Insect mesh, PVC-coated fibreglass.
-
-
Additional properties
Blanking panels
Not required., Single-skin aluminium panels, standard powder-coated black to one face only., Single-skin aluminium panels, powder-coated black to both sides., Single-skin aluminium panels, powder-coated to match louvre., Single-skin aluminium panels, mill finish., Insulated panels incorporating A1-classified non-combustible stone wool core., Insulated panels, extruded polystyrene core.
-
-
Sustainability data
Material
Carbon steel, Mineral wool
-
-
