Summary
Hard wearing, durable and hygienic surfacing material used for multiple applications including interior doors, contract furniture, shopfitting, wall panelling and washroom environments.
-
-
Application
Suitable for both horizontal and vertical general purpose within applications including:
- Counters.
- Reception desks and furniture.
- Interior doors.
- Shopfitting.
- Wall panelling.
- Washroom environments.
-
-
Description
Hard wearing, durable and hygienic surfacing material used for multiple applications including interior doors, contract furniture, shopfitting, wall panelling and washroom environments. Available in 62 patterns.
Features and benefits:
- Durable and wear resistant.
- Hygienic.
- Low maintenance and easy to clean.
Available in different patterns:
- Optical Solid.
- Textile/ Woven.
- Metal Look.
- Geometric.
- Material.
True Scale:
TrueScale laminates utilize the latest high definition printing techniques to create large, true to life prints.
Finish: AR Plus®.
Frosted:
Choice of 4 colours in AR Plus finish: Dusk, jade, gold and copper.
Finish: AR Plus®, Satin NDF™, Etchings™, Naturelle™, Honed™, Puregrain™.
Technical characteristics:
- Dry heat resistance To EN 438-2: 16),Gloss finish - ≥ Rating 3, Other finish - ≥ Rating 4.
- Wet heat resistance To EN 438-2: 18, Gloss finish - ≥ Rating 3, Other finish - ≥ Rating 4.
- Formability To EN 438-2: 31, L (mm) - ≤ 10 x t , T (mm) - ≤ 20 x t (HGP/PAR Only).
- Blistering resistance To EN 438-33, < 0.8mm - 10s, ≥ 0.8mm - 15s (HGP/PAR Only).
-
-
Digital objects
-
-
Color
Beige, Black, Blue, Brown, Grey, Orange, Red, White
-
-
Finish
Gloss, Honed, Matt, Other
-
-
Material
High pressure laminate (HPL)
-
-
Shape
Rectangle
-
-
Length
2150 mm, 2350 mm, 3050 mm, 3660 mm
-
-
Width
950 mm, 1300 mm, 1525 mm
-
-
Height
0.7 mm, 2 mm, 2.5 mm, 3 mm, 4 mm, 6 mm, 7 mm, 10 mm, 12 mm, 13 mm, 16 mm, 18 mm, 20 mm
-
-
Warranty description
One year
-
-
Specification
Grade
HPL/EN438-3 HGP., HPL/EN438-3 HGS.
-
-
Fire performance
To EN 13501-1, 4.0 mm ≤ t, D-s2,d0.
-
-
Thickness
0.7 mm.
-
-
Panel size
-
-
-
Length
2150 mm., 2350 mm., 3050 mm., 3660 mm.
-
-
Width
950 mm., 1300 mm., 1525 mm.
-
-
Finish
AR Plus® (AB)., Honed™ (AHD)., Matte 58™ (MAT)., Plex™ (PLX).
-
-
Colour
F0193 Xenon., F0202 Light Gauze., F1330 Calcium New., F1782 Stardust., F1787 Grey Dust., F1936 Lava Dust., F3734 Radon, F3735 Krypton., F5270 Geo White., F5272 Geo Folkestone., F5273 Geo Citadel., F5278 Dogbone Earth., F5279 Dogbone Otter., F5280 Dogbone Grey., F5281 Dogbone White., F5282 Dogbone Black., F5283 Dogbone Storm., F5583 Steel Metal., F5593 Silver Metal., F6213 Cherry Strand., F6698 Paloma Polar., F6723 Paloma Almond., F6724 Paloma Folkestone., F6725 Paloma Just Blue., F6727 Paloma Just Rose., F6728 Paloma Jade., F6943 VirrVarr White., F6945 VirrVarr Black., F7507 Folkestone Grafix., F7508 Mouse Grafix., F7515 Graphite Grafix., F7517 Almond Grafix., F7522 Blue Silk Grafix., F7708 Flax Gauze., F8837 Brushed Zinc., F8859 Vintage Brush., F8826 Neutral Twill., F8827 Sarum Twill., F8829 Graphite Twill., F6362 Concrete Formwood., F6363 Elemental Ash., F8830 Elemental Concrete., F8832 Elemental Corten., F8833 Elemental Graphite.
-
-
Additional properties
Density
To EN ISO 1183-1, ≥ 1.35g/cm³
-
-
Dimensional stability
To EN 438-2: 17, Longitudial - ≤ 0.55%, Transversal - ≤ 1.05%.
-
-
Impact resistance
To EN 438-2: 20): ≥ 20N.
-
-
Lightfastness
To EN 438-2: 27, ≥ 4 Contrast.
-
-
Pattern
Optical Solid., Textile/Woven., Metal Look., Geometric., Material.
-
-
Scratch resistance
To EN 438-2: 25, Smooth - ≥ Rating 2, Textured - ≥ Rating 3.
-
-
Sheet size
3050 x 1300 mm., 2150 x 950 mm., 2350 x 950 mm., 2350 x 1300 mm., 3660 x 1525 mm.
-
-
Stain Resistance
To EN 438-2: 26, (Group 1+2) ≥ Rating 4, (Group 3) ≥ Rating 4.
-
-
Standards
To EN 438.
-
-
Water resistance
EN 438-2: 12, Gloss finish - ≥ Rating 3, Other - ≥ Rating 4.
-
-
Water vapour resistance
To EN 438-2: 14, Gloss finish - ≥ Rating 3, Other finish - ≥ Rating 4.
-
-
Wear resistance
To EN 438-2: 10, ≥150 revolutions.
-
-
Sustainability data
Contains Red List materials
No
-
-
Country of material origin
United Kingdom
-
-
Country of product manufacture
United Kingdom
-
-
Recyclability
Non-reusable
-
-
