Summary
Insulated roller shutters. British manufactured, environmental shutters, standard or high speed.
Insulated roller shutters. British manufactured, environmental shutters, standard or high speed.
Application
For commercial use. Applications include:
- Manufacturing buildings.
- Industrial buildings.
- Storage/ distribution warehouses.
- Secure areas where frequent access is required (high-speed model only).
For commercial use. Applications include:
- Manufacturing buildings.
- Industrial buildings.
- Storage/ distribution warehouses.
- Secure areas where frequent access is required (high-speed model only).
Description
Electrically operated steel roller shutter with 85 x 25 mm double skin interlocking galvanized steel laths and nylon end locks. This shutter is designed to comply with the current British and EEC safety regulations. Optional specification levels can be varied to meet any special operational requirements.
Features and benefits:
- Compliant with PR EN 13241-1:2003, manufactured and installed to ISO 9001/2001 and is CE marked.
- Constructed from 85 x 25 mm double skin interlocking galvanized steel sections and retained at ends by nylon end locks.
- The door curtain is made up from an insulated lath section giving a thermal insulation value of 0.69 W/m²K across the lath section and an acoustic value reduction of 18 dB across the lath section.
- Fitted with a purpose-designed extrusion complete with interlocking EPDM rubber weather seal.
- Full automatic operation via control panel by remote induction loop, radio control, with full safety systems. (optional)
Electrically operated steel roller shutter with 85 x 25 mm double skin interlocking galvanized steel laths and nylon end locks. This shutter is designed to comply with the current British and EEC safety regulations. Optional specification levels can be varied to meet any special operational requirements.
Features and benefits:
- Compliant with PR EN 13241-1:2003, manufactured and installed to ISO 9001/2001 and is CE marked.
- Constructed from 85 x 25 mm double skin interlocking galvanized steel sections and retained at ends by nylon end locks.
- The door curtain is made up from an insulated lath section giving a thermal insulation value of 0.69 W/m²K across the lath section and an acoustic value reduction of 18 dB across the lath section.
- Fitted with a purpose-designed extrusion complete with interlocking EPDM rubber weather seal.
- Full automatic operation via control panel by remote induction loop, radio control, with full safety systems. (optional)
Color
Grey
Grey
Finish
Galvanized
Galvanized
Material
Steel, Rubber
Steel, Rubber
Shape
Rectangle, Square
Rectangle, Square
Length
Bespoke
Bespoke
Width
Bespoke
Bespoke
Height
Bespoke
Bespoke
Warranty description
One year
One year
Specification
Classification data
Standard
LPCB assessed/ approved; UL Listed; CE marked.
LPCB assessed/ approved; UL Listed; CE marked.
Opening sizes
Up to 10 000 mm.
Up to 10 000 mm.
Format
Thermally insulated.
Thermally insulated.
Arrangement
Vertical, fitted into reveal.
Vertical, fitted into reveal.
Performance
-
-
Watertightness
Manufacturer's standard.
Manufacturer's standard.
Resistance to wind load
Manufacturer's standard.
Manufacturer's standard.
Acoustic performance
18 dB.
18 dB.
Thermal resistance
0.69 W/m²K.
0.69 W/m²K.
Shutter curtain
-
-
Lath material
Steel., Aluminium.
Steel., Aluminium.
Profile
Flat.
Flat.
Finish and colour
Galvanized., Plastisol coated, colour., Powder coated, colour.
Galvanized., Plastisol coated, colour., Powder coated, colour.
Frame and guides
-
-
Material
Steel.
Steel.
Finish
Galvanized.
Galvanized.
Colour
Silver., RAL.
Silver., RAL.
Installation fasteners
Three no. M12 hex bolts.
Three no. M12 hex bolts.
Operation
-
-
Mode
Automatic., Manual, push button., Manual, security key switch.
Automatic., Manual, push button., Manual, security key switch.
Accessories
None., Hood covers and flashings., Motor hood covers and flashings., ATEX compliance., Vision windows.
None., Hood covers and flashings., Motor hood covers and flashings., ATEX compliance., Vision windows.
Additional properties
Opening speed
0.1–0.2 m/s.
0.5–0.8 m/s.
Sustainability data
Country of product manufacture
United Kingdom
United Kingdom
