Summary
ADAGIO Acoustic+ 30 mm tile.
Color
White
-
-
Material
Mineral wool
-
-
Shape
Square, Rectangle
-
-
Length
600 mm, 625 mm, 675 mm, 1200 mm, 1250 mm, 1350 mm, 1500 mm, 1800 mm
-
-
Width
300 mm, 600 mm, 625 mm, 675 mm
-
-
Height
30 mm
-
-
WarrantyDescription
Ten year, 25 year
-
-
Specification
Standard
To ISO 4, EN ISO 14644-1.
-
-
Third-party certification
Indoor Air Quality Gold, Cradle to Cradle Certified® Bronze.
-
-
Fire performance
-
-
-
Reaction to fire
To EN 13501-1, Euroclass A2-s1, d0.
-
-
Unit type
Ceiling tile.
-
-
Material
Mineral wool.
-
-
Recycled content
49%.
-
-
Unit size
-
-
-
Face dimensions
600 x 600 mm., 625 x 625 mm., 675 x 675 mm., 1200 x 600 mm., 1250 x 625 mm., 1350 x 300 mm., 1350 x 600 mm.
-
-
Thickness
30 mm.
-
-
Surface texture
Plain.
-
-
Colour
White.
-
-
Edge profile
Square.
-
-
Additional properties
Weight
8.2 kg/m².
-
-
Sound absorption
To EN ISO 11654 and EN ISO 354, αw = 0.90 (class A).
-
-
Sound reduction
To EN ISO 10140-2 and EN ISO 717-1, Rw = 22 dB.
-
-
Light reflectance
90%.
-
-
ThermalConductivity
To EN 12667, λ = 0.060 W/mk.
-
-
Air permeability
To DIN 18177, PM1 (≤ 30 m³/hm²).
-
-
Constant humidity resistance
95% RH.
-
-
Sound attenuation
To EN ISO 10848-2 and EN ISO 717-1, Dn,f,w =40 dB.
-
-
System
Exposed demountable - System C., Exposed - Bandraster, demountable - System I.3., Exposed - Corridor, demountable - System F.3.
-
-
Sustainability data
Recycled content
49 %
-
-
