Suitable for military applications as well as for use in high security areas such as petrochemical plants, banks and embassies.

For security reasons, fabricators require special approval to utilize this system.

The system allows single and double-leaf outward-opening door solutions to be designed with blast-resistant properties, whilst meeting all the requirements of normal doors with regard to thermal insulation, sound reduction and weathertightness.

Features and benefits:

• Door system tested in accordance with ISO 16933 with the classification EXV 19 (level E “low hazard”).
• Extended area of application based on calculations possible.
• System approval in accordance with EN 14351-1 available
• Doors up to maximum 300 kg leaf weight in conjunction with three-part surface-mounted.
• U_f value in accordance with DIN EN ISO 10077-2: to U_f = 2.3 W/m²K.
• For security reasons, fabricators require special approval to utilize this system.
• Combination with blast-resistant Schüco façade systems on request.
• Optional panic function construction: single-leaf doors in combination with Schüco SafeMatic lock, double-leaf doors with Schüco claw bolt and pin lock.

Standards:

• ISO 16933.
• EN 179.
• EN 1125.
• EN 14351-1.
