Summary
Rainline rainwater downpipes and fittings with an unpainted, galvanized surface finish.
-
-
Application
For use in varying applications, including:
- Large or small roof areas.
- Classic or contemporary buildings.
- Domestic or commercial use.
When selecting gutter and pipe sizes for a rainwater system, the size of the roof and the downpipes (specified separately) position should be considered. This helps ensure that typical rainfall will not cause system overflow. Consult manufacturer for further details.
-
-
Description
Rainline rainwater downpipes and fittings with an unpainted, galvanized surface finish.
Features and benefits:
- Provides an attractive, organic aesthetic.
- Will weather to a dark grey, metallic appearance within 3–5 years after installation.
- Low carbon footprint and low overall environmental impact.
- Durable and flexible.
- Manufactured from 30% recycled steel, which is lighter than cast iron, easier to handle than aluminium and offers minimal thermal movement compared to plastic.
- Minimal maintenance required.
- Highly resistant to attack from vandals.
- UV stable.
- Available in four sizes, three lengths, and a range of colour options. Consult manufacturer's literature for details.
- Quick and easy to install.
- Supplied with a ten-year warranty.
- Manufactured in accordance with BS EN 12056-3: 2000.
-
-
Product certifications
-
-
Finish
Galvanized
-
-
Material
Steel
-
-
Shape
Circle
-
-
Length
3000 mm
-
-
WarrantyDescription
Ten year
-
-
Specification
Classification data
Material
Steel.
-
-
Section
Round.
-
-
Size (nominal)
100 x 1000 mm., 100 x 2500 mm., 100 x 3000 mm.
-
-
Finish and colour
-
-
-
Finish
Galvanized.
-
-
Colour
Self-coloured.
-
-
Integral accessories
Selection of brackets, sliding pipes, diverters, hoppers, shoes, connectors, branches, access pipes, offsets and intermediate pipes are available dependent on size.
-
-
Additional properties
Type
100 mm downpipe, 1 m length (SROR1100MG)., 100 mm downpipe, 2.5 m length (SROR25100MG)., 100 mm downpipe, 3 m length (SROR3100MG).
-
-
Bends
BK 70° conical pipe bend, 100 mm (BK70100MG)., BM 70° pipe bend with socket, 100 mm (BM70100MG).
-
-
Intermediate pipes
100 mm MST intermediate pipe, 1 m (MST1100MG)., As drawing., Contractors choice.
-
-
Offsets
SOKN one-piece offset, 100 mm (SOKN100MG)., As drawing., Contractors choice.
-
-
Access pipes
100 mm MSTRA rod access pipe, 1 m (MSTRA100MG)., As drawing., Contractors choice.
-
-
Branches
GROR pipe branch, 100 mm (GROR100MG)., As drawing., Contractors choice.
-
-
Connectors
SRORM pipe connector, 100 mm (SRORM100MG)., As drawing., Contractors choice.
-
-
Shoes
BUTK drain shoe, 100 mm (BUTK100MG)., UTK pipe shoe, 100 mm (UTK100MG)., As drawing., Contractors choice.
-
-
Hoppers
VATKL large water hopper, 100 mm (VATKL100MG)., As drawing., Contractors choice.
-
-
Diverters
FUTK adjustable diverter, 100 mm (FUTK100MG)., As drawing., Contractors choice.
-
-
Sliding pipe
PRT sliding pipe, 100 mm (PRT100MG)., As drawing., Contractors choice.
-
-
Brackets
SHVA downpipe bracket, 100 mm (SVHA100MG)., As drawing., Contractors choice.
-
-
Hose connector
As drawing., Contractors choice.
-
-
Pipe holders
SST spike for pipe holder, 125 mm (SST125)., SST spike for pipe holder, 175 mm (SST175)., SST spike for pipe holder, 250 mm (SST250)., SST spike for pipe holder, 300 mm (SST300)., SV pipe holder (for Spike), 100 mm (SV100MG)., As drawing., Contractors choice.
-
-
Sustainability data
Contains Red List materials
No
-
-
Country of material origin
Sweden
-
-
Country of product manufacture
Sweden
-
-
Recyclability
Fully recycleable
-
-
Recycled content
30 %
-
-
