Summary
Insulation for rainscreen cladding systems.
-
-
Application
Insulation for use behind rainscreen facades.
-
-
Description
Premium performance rigid thermoset phenolic insulation for use behind rainscreen facades with a core manufactured using a blowing agent that has zero ozone depletion potential (ODP) and low global warming potential (GWP).
Manufactured in accordance with ISO 9001: 2015 (Quality Management Systems. Requirements), ISO 14001: 2015 (Environmental Management Systems. Requirements), ISO 45001: 2018 (Occupational Health and Safety Management Systems) and ISO 50001: 2018 (Energy Management Systems. Requirements with guidance for use).
-
-
Color
Pink
-
-
Finish
Smooth
-
-
Material
Resin
-
-
Shape
Rectangle
-
-
Length
2400 mm
-
-
Width
1200 mm
-
-
Height
25 mm, 30 mm, 40 mm, 50 mm, 60 mm, 70 mm, 75 mm, 80 mm, 90 mm, 100 mm, 110 mm, 120 mm, 130 mm, 140 mm, 150 mm
-
-
Specification
Classification data
Standard
To BS EN 13166.
-
-
Third party product certification
British Board of Agrément (BBA) certification.
-
-
Fire performance
Euroclass RtF C-s2,d0 when classified to EN 13501-1: 2018.
-
-
Thermal conductivity (maximum)
0.022 W/m∙K.
-
-
Cross section
Uniform thickness.
-
-
Thickness
25 mm.
-
-
Face size (length x width)
2400 x 1200 mm.
-
-
Compressive strength (minimum) at 10% compression
100 kPa.
-
-
Recycled content
0% (minimum) to BS EN ISO 14021.
-
-
Edges
Square.
-
-
Facing
Low emissivity composite foil.
-
-
Additional properties
Global warming potential
Less than 5.
-
-
Ozone depletion potential
Zero.
-
-
Core
Rigid thermoset fibre-free phenolic insulant core.
-
-
Sustainability data
Country of product manufacture
Ireland
-
-
A1–A3 ('Production stage')
Embodied carbon as defined in BS EN 15804
Normalized unit
-
-
-
Declared unit
6.02 kg·CO₂e/kg
-
-
Recycled content
0.75 %
-
-
