Wonderglas - GC - Skylight roofing and cladding

Verified by manufacturer over a year ago

Ampelite Australia

Wonderglas GC (GC = Gel Coated Surface) is a UV protected GRP (Glass reinforced polyester) sheeting product.

Jump to:
+ 61 3 8710 9110 Website

Application

Used within a wide range of applications.

Description

UV protected glass reinforced polyester (GRP) sheeting with a gel coated surface which has been chemically cross bonded to the sheet. Some of its features include:


  • Hail Resistance
  • Stable Light Transmission
  • UV Stable 100 Micron Gel Coating
  • Cuts 99% of UV Transmission
  • Low Surface Erosion
  • Chemical Resistance


General information

Color

Clear

Other

Manufacturer guidance

Available in Ice-Clear, Opal, Cool-lite.

Finish

Coated

Material

Fiber-glass

Shape

Trapezoid

Other

Length

Bespoke

Width

Bespoke

Height

Bespoke

Warranty description

25 year

Uniclass

Pr_25_71_63_34 Glass-reinforced plastics (GRP) profiled sheetsPrimary

NATSPEC National Classification System

0431 Cladding - Combined

0429 Roofing - Glazed

0421 Roofing - Combined

SpecPack

08900 Glazed Curtain Walls

08620 Skylights

SpeedSpec

08620 Skylights

07610 Roofing and Roof Plumbing

07462 Cladding External Walls

Specification data - Glass-reinforced plastics (GRP) profiled sheets

Standard

To AS 4256.3.

Guidance for specification option:

 The product must be installed strictly in accordance with AS1562.3 Design and installation of sheet roofing and wall cladding Part 3: Plastic, and with the Manufacturer’s recommendations and specifications

Classification

-

Grade

2.4 kg/m³.

3.05 kg/m³.

Profile

406 Decking.

Guidance for specification option:

406 mm cover. 1º minimum pitch.

450 Decking.

Guidance for specification option:

450 mm cover. 1º minimum pitch.

5 Rib.

Guidance for specification option:

760 mm cover. 2º minimum pitch.

500 Decking.

Guidance for specification option:

500 mm cover. 1º minimum pitch.

650 Prodek.

Guidance for specification option:

650 mm cover. 2º minimum pitch.

Alcan LT7.

Guidance for specification option:

890 mm cover. 3º minimum pitch.

Corrugated.

Guidance for specification option:

760 mm cover. 5º minimum pitch.

Hardies Super 61.

Guidance for specification option:

003 mm cover. 5º minimum pitch.

Klip-lok 700, Speed Deck Ultra.

Guidance for specification option:

700 mm cover. 1º minimum pitch.

Kliplok 406.

Guidance for specification option:

406 mm cover. 1º minimum pitch.

Long Span.

Guidance for specification option:

700 mm cover. 3º minimum pitch.

Spandek Hi-Ten.

Guidance for specification option:

700 mm cover. 3º minimum pitch.

Length

Can be made to order.

Cover width

450 mm.

Guidance for specification option:

450 Decking

406 mm.

Guidance for specification option:

Kliplok 406

406 Decking

500 mm.

Guidance for specification option:

500 Decking

650 mm.

Guidance for specification option:

650 Prodek

700 mm.

Guidance for specification option:

Spandek Hi-ten

Long span

Klip-lok 700

Speed deck ultra

760 mm.

Guidance for specification option:

Corrugated

Five rib

890 mm.

Guidance for specification option:

Alcan LT7

1003 mm.

Guidance for specification option:

Hardies super 6

Colour

Cool-Lite.

Guidance for specification option:

38% light transmission, 23.5% heat transmission.

Ice Clear.

Guidance for specification option:

74% light transmission, 68% heat transmission.

Opal.

Guidance for specification option:

72% light transmission, 64% heat transmission.

Accessories

FS Firecheck.

Manufacturer guidance

Consult manufacturer for details.

Sustainability data

Country of material origin

Australia

Country of product manufacture

Australia

Recyclability

No

Recycled content

As defined in clause 7.8 of BS EN ISO 14021

0 %

Literature

Wonderglas GC - gel coated polyester sheeting

Wonderglas GC - gel coated polyester sheeting
