Application

Buildings and structures with multiple openings.

Description

Louvre system ideal for projects where economy is the primary consideration, high free area is important and occasional water penetration will not cause significant problems.


General information

Warranty description

30 years.

Guidance for specification option:

Powder coating warranty.

Uniclass

Pr_30_59_48_04 Aluminium louvre panel unitsPrimary

NATSPEC National Classification System

0457 External Screens

SpecPack

10240 Grilles and Screens

SpeedSpec

08520 Metal Windows and Glazed Doors

Specification data - Aluminium louvre panel units

Size (l x w x d)

-

Manufacturer guidance

Refer to manufacturer for maximum height and widths.

Material

Aluminium.

Finish

-

Coating

Powder-coated.

Colour

-

Manufacturer guidance

Refer to manufacturer for range of colours available.

Construction

Visible mullions.

Air intake and exhaust performance

-

Standard

To AS/NZS 4740.

Louvre configuration

-

Blade orientation

Horizontal.

Blade pitch

70 mm.

Blade angle

Fixed.

Depth

79 mm.
