Harlequin Activity - Vinyl Top

Verified by manufacturer over a year ago

Harlequin (Australia)

A permanently installed sprung floor system finished with a Harlequin vinyl performance floor, selected from our range.

Jump to:
+61 2 9620 7770 Website

Application

Ballet, contemporary, modern and theatrical use, aerobics, zumba, hip-hop, jazz, street, salsa, percussive including flamenco, Irish and tap, multi-purpose use, concerts and for operatic performances.

Description

A permanently installed sprung floor system, based on the well-established ‘triple sandwich’ construction originated by Harlequin over 30 years ago. It’s a fully-floating system with no fixings to the sub-floor and can be laid on any reasonably smooth and flat surface without prior preparation.


Harlequin Activity is shock-damped to avoid a ‘trampoline’ effect and provides area and point elasticity to offer identical characteristics across the whole floor. It is an 'industry standard’ choice with many hundreds of installations worldwide, effectively reducing injuries to both teachers and performers.


Harlequin Activity is installed by our own highly-skilled technical team and is finished with a Harlequin vinyl performance floor, selected from our range with colour matched composite edging profile.

General information

Color

-

Manufacturer guidance

Available in:

  • Black
  • Dark Grey
  • Grey
  • Light Grey
  • Oak Strip Effect
  • White

Finish

Depends on vinyl top surface chosen.

Material

Vinyl.

Warranty description

5 year.

Uniclass

Ss_30_42_72_72 Resilient sheet floor covering systemsPrimary

NATSPEC National Classification System

0654 Multilayered Board Flooring

SpeedSpec

09646 Floating Flooring

SpecPack

09620 Sports Flooring

09646 Floating Flooring

Specification data - Resilient sheet floor covering systems

Rigid underlay

-

Type

Cellular polyurethane with a dual layer semi-flexible suspension panel.

Fasteners

Staples.

Resilient underlayer

-

Fixing

Acrylic polymer emulsion adhesive/ Water based rubber resin adhesive.

Sheet

-

Type

Vinyl.

Fixing

Acrylic polymer emulsion adhesive/ Water based rubber resin adhesive.

Seams

Welded.

Skirtings and trims

Edge profiles.

Substrate preparation

Can be laid on any hard, smooth sub-floor.

Temperature conditions for use

Room temperature 18c-27c, Humidity 40-6-%.

Load (maximum)

Maximum point load - 549kg.

Design load

Rolling load >1500N.

FloorCoveringThickness

Minimum floor thickness before inclusion of chosen finish - 46mm.

Sustainability data

Country of material origin

Australia

Country of product manufacture

Australia
