Boulevard™ Cyclonic (COLORBOND® Steel)

Verified by manufacturer over a year ago

COLORBOND® Steel

Fielders Variant:

Wall cladding system with a flat, recessed joint look.

Jump to:
+61 8 8292 3611 Website

Application

Suitable for wall cladding applications that require a flat, recessed look.


AUSTRALIAN STANDARDS



Published load capacity data is derived from testing in accordance with:

  •       AS 4040.0:1992.
  •       AS 4040.1:1992.
  •       AS 4040.2:1992.
  •       AS 4040.3:2018.



Published Limit state capacities are suitable to determine structural adequacy and serviceability in accordance with:

  •       AS/NZS 1170.0:2002 Structural design actions, Part 0: General principles.
  •       AS/NZS 1170.1:2002 (Reconfirmed 2016) Structural design actions, Part 1: Permanent, imposed and other actions.
  •       AS/NZS 1170.2:2011 (Reconfirmed 2016) Structural design actions, Part 2: Wind actions.
  •       AS/NZS 1170.3:2011 (Reconfirmed 2016) Structural design actions, Part 3: Snow and ice actions.



Published installation guidelines align with AS 1562.1:2018 Design and Installation of sheet and wall cladding.



Fielders steel products comply with:

  •       AS 1397:2011 Continuous hot-dip metallic coated steel sheet and strip - Coatings of zinc and zinc alloyed with aluminium and magnesium.
  •       AS/NZS 2728:2013 Prefinished/prepainted sheet metal products for interior/exterior building applications - Performance requirements.
  •       AS 1397:2011 which defines the coating types and classes and steel grades for hot dip metallic coated steel.

Description

Boulevard™ is a wall cladding system with a flat, recessed joint look achieved through interlocking panels that are pierce-fixed and installed with a ventilated air space. Some features of this system include:

  • Contemporary design.
  • Can be laid horizontally or vertically.
  • Available in a wide array of colours and finishes.
  • Available in a range of sizes.

General information

Material

Steel.

Shape

Rectangle

Warranty description

-

Manufacturer guidance

Project specific material warranties available. Contact manufacturer for details.

Uniclass

Pr_25_71_51_15 Carbon steel sheetsPrimary

SpeedSpec

07462 Cladding External Walls

NATSPEC National Classification System

0436 Cladding – Profiled and Seamed Sheet Metal

SpecPack

07600 Metal Roofing, Siding and Roof Plumbing

Specification data - Carbon steel sheets

Standards

To AS 1397, AS/NZS 1365 and AS/NZS 2728.

Guidance for specification option:

Installation of the cladding should be in accordance with AS 1562.1 and HB 39.

Structural grade

G300.

Coating

-

Class

AM100.

Size

-

Length

-

Manufacturer guidance

Sheets are supplied custom cut to length to suit project requirements. Transportation limits apply.


Panels come in lengths of 0.50 m to 8.0 m, with longitudinal joint widths of 5 mm to 18 mm (with 15 mm as standard).


Provide manufacturing tolerance of ±7 mm in length.

Width

285 mm.

485 mm.

Manufacturer guidance

Comes with a side depth of 22 mm. Provide manufacturing tolerance of ±4 mm in cover width.


Other widths are available, subject to minimum order quantity. Contact local manufacturer for details.

Thickness

0.55 mm.

Guidance for specification option:

Total Coated Thickness of 0.60 mm.

0.75 mm.

Guidance for specification option:

Total Coated Thickness of 0.80 mm.

Subject to minimum order quantities.

Manufacturer guidance

Refers to Base Metal Thickness or BMT.

Indicated Total Coated Thickness (TCT) is based on standard COLORBOND®, single-sided material.

Finish

-

Applied

Painted.

Colour

Basalt.

Classic Cream.

Cottage Green.

Cove.

Deep Ocean.

Show more

Material

COLORBOND® steel.

Cyclonic performance

To AS/NZS 1170.2:2011, AS 4040.1:1992, AS 4040.3:2018 and AS 4055:2012.

Thermal expansion

2.9 mm average per 5.0 m.

Manufacturer guidance

Computed at 50° C change.

Frame or support

Plywood.

Guidance for specification option:

To be supported with purlins of minimum 1.00 mm BMT G550, with maximum spans of 600 mm.


Affix with 10g-16 x 25 mm Wafer or Low Profile Hex Head Type 17 screws with a minimum class 3 coating.

Steel Batten.

Guidance for specification option:

Steel battens should be 40 mm x 0.75 mm BMT G550, with maximum spans of 450 mm. This is to be supported with purlins of minimum 1.00 mm BMT G550, with maximum spans of 1500 mm.


Affix with 10g-16 x 16 mm Wafer or Low Profile Hex Head Tek screws with a minimum class 3 coating.

KingFlor® KF40®.

Guidance for specification option:

For resistance to wind-borne debris, KF40 backing is required.

KF40 should be 0.75 mm BMT, to be supported by wall girts of 1200 mm maximum spans. If panels are to be installed vertically, steel battens with 1200 mm maximum spans should be added.


Affix with 10g-16 x 16 mm Wafer Head Tek screws through both over and under lap legs.

Manufacturer guidance

Refers to recommended substrate and fasteners if product is to be installed without insulation.

Mass

5.31 – 5.92 kg/m² (0.55 mm BMT).

6.71 – 7.47 kg/m² (0.75 mm BMT).

Insulation

-

Manufacturer guidance

When insulation thickness up to 50 mm are installed, screws may need to be increased in number depending on insulation thickness and density.


When insulation is required, Fielders® recommends the use of a thermal spacer.

Installation

Concealed pierced-fixed.

Manufacturer guidance

Boulevard™ needs to be fitted on a water tight barrier, which may consist of a precast wall, steel sheeting backing (such as Panelform™) or another waterproof membrane.


Fielders® recommends the use of Panelform™.

Sustainability data

Country of material origin

Australia

Country of product manufacture

Australia

Recyclability

100% Recyclable.
