Mono 10 PVC-U Trunking

Verified by manufacturer 1 month ago

Marshall-Tufflex Ltd

A compact trunking that is suited for the smaller office or workshop area.

Jump to:
+44 (0)1424 856600 Website

Application

Suitable for use in dado applications and as a feeder trunking as well as suited for the smaller office or workshop area.

Description

A compact trunking that is suited for the smaller office or workshop area.


Features and benefits:

  • One main compartment.
  • Can be subdivided.
  • Suitable for dado application and as a feeder trunking.
  • Self extinguishing and non-flame propagating PVC-U.
  • Fire clips available to secure cables within trunking and prevent premature collapse in the event of a fire.
  • Compliant up to Cat 7a.
  • Standard bend radius 25 mm.
  • Adjustable data box 32–40 mm.

General information

Color

White

Guidance for specification option:

White (RAL9003).

Finish

Matt

Material

PVC-U

Shape

Rectangle

Length

3000 mm

Width

50 mm

Height

100 mm

Uniclass

Pr_65_70_11_96 Wall and ceiling-mounted cable trunking and ductingPrimary

CAWS

V90/350 Cable trunking and cable ducting for wall and ceiling mounting

V90/350 Cable trunking and cable ducting for wall and ceiling mounting

Sustainability data

Country of material origin

United Kingdom

Country of product manufacture

United Kingdom

Recyclability

100%

Recycled content

As defined in clause 7.8 of BS EN ISO 14021

70 %

BIM objects

Platform Compatible Version
Revit
-

1

Literature

Mono 10 PVC-U Trunking Product Data Sheet

Mono 10 PVC-U Trunking Product Data Sheet
