Paxton10 Wireless Connector

Name: Paxton10 Wireless Connector
Brand: Paxton Access Ltd
SKU: buk6U68yTHfY956Fc8R1M

Verifierad av tillverkaren för 4 månader sedan

The wireless connector enables the award-winning PaxLock Pro to connect to the Paxton10 system. The wireless connector communicates to the PaxLock Pro via Bluetooth®.

Hoppa till:

BOS

+44 (0)1273 811011 Webbplats

Applikation

Suitable for either wall or ceiling mounted installation within the Paxton10 system.

Beskrivning

The Paxton10 Wireless Connector is a sleek and discreet interface to support wireless functionality within the Paxton10 system, it can be wall or ceiling mounted.

The connector plugs directly into a port on the Paxton10 Door or Video controller. Connectors are powered by the controller. Each connector can register up to 10 PaxLock Pro units. Maximum communication distance is 15-20 meters.

The connector’s compact, modern appearance makes it suitable for visible mounting on a wall or ceiling. Mounting is straightforward using the supplied mounting plate.

Features and benefits:

Built-in Bluetooth wireless technology (2.4 GHz), to support the installation of Paxton10 PaxLock Pro.
Intelligently controlled through Paxton10 software.
Cascade up to three connectors from a single controller.
Connects to any Paxton10 controller.
Wireless range of 15 m.
Surface, backbox mounted.

Allmän information

Färg	White
Material	Plastic Vägledning för specifikationsalternativ: ABS/ PCB.
Form	Other
Längd	163 mm
Bredd	164 mm
Höjd	34 mm
Garantibeskrivning	Five year

Uniclass	Ss_75_40_02_11 Kortbaserade passerkontrollsystemPrimär
CAWS	W90/363 Access control units W90/130 Electronic access control system

SKU Code	010-687

Product range	Paxton10 Connectors

Specifikationsdata - Kortbaserade passerkontrollsystem

Klassificeringsdata
System supplier	Paxton Access Limited.
System type	Networked.
Equipment interconnectivity	Wireless. Vägledning för specifikationsalternativ: BLE - Bluetooth low energy.
Control software	Paxton10.
Rewireable installation	Required.
Connection	100 m. Vägledning för specifikationsalternativ: Controller to connector/connector to controller. Tillverkarens vägledning Maximum dataline connection.
Frekvens	Bluetooth 2.4 GHz.
LED	Green LED - Health, communications; Blue LED - Bluetooth.
Driftstemperatur	0–45°C.
Operating voltage	30 V d.c.
Strömförbrukning	300 mA (max).
Integral accessories	Paxton10 Server.
