Alnwick Blend- Clay Facing Brick
Verifierad av tillverkaren för 4 dagar sedan
Rolled facing brick.
Applikation
Brickwork applications.
Beskrivning
Rolled facing brick.
Features and benefits:
- Brick pack quantity (500).
- Brick packs supplied banded (plastic) and shrinkwrapped packaged.
- Brick voids (25-30).
- EAN number (5036335195475).
- Factory: THR.
Allmän information
Färg | Red |
ytbehandling | Rolled |
Material | Clay |
Form | Rectangle |
Längd | 215 mm |
Bredd | 102 mm |
Höjd | 65 mm |
Uniclass | |
CAWS | Q1/320 Clay brick pavers F1/304 Facing bricks Q10/130 Clay brick F10/110 Clay facing brickwork Q10/20 Clay brick F10/5 Facing brickwork |
SKU Code | A2801A |
GTIN/EAN | 5036335195475 |
Specifikationsdata - Tegel
Klassificeringsdata | |
Standard | To BS EN 771-1. |
Brick description | Rolled facing brick. |
Work size (length x width x height) | 215 x 102 x 65 mm. |
Tolerances | |
Mean value | T2. |
Range | R1. |
Compressive strength | |
Mean compressive strength (minimum) | 60 N/mm². |
Durability designation | F2~. |
Density | |
Gross dry | 1560 kg/m³. |
Tolerance | T2, R1. |
Water absorption | 10%. Vägledning för specifikationsalternativ: Suction rate (0.7 Kg/m².min). |
Configuration | Vertically perforated. |
Thermal conductivity | 1.13 kVal. |
Water vapour permeability | 50/100 µ. |
Bond strength | 0.15 N/mm². |
Reaction to fire | Class A1 to BS EN 13501-1. |
Vikt | 2.2 kg. |
Type | Wirecut. |
Active soluble salts | S2. |
Hållbarhetsdata
Materialets ursprungsland | United Kingdom |
Produktens tillverkningsland | United Kingdom |
Material | Clay |
BIM-objekt
Detta BIM-objekt har skapats för att uppfylla kraven i
Läs mer om
| Plattform | Kompatibel | Version |
|---|---|---|
 Revit | - | 1 |
 IFC | - | 1 |
