After a particularly contentious and protracted planning process, this semi-detached, red-bricked house, part of a group of five properties that form Regent’s Mews in affluent London NW8, finally boasts an impressive third storey extension as a result of the erection of a mansard roof.The new dormer windows to its front aspect lend this 1980’s property a delightfully modern aesthetic, whilst the provision of a green roof to the rear aspect underlines its eco-credentials. The installation of Glazing Vision’s elegant sliding-over fixed rooflight above the stairwell, together with 4 additional fixed rooflights, has maximised the light streaming into this new living space, and also provided an all-important source of ventilation.Initial proposals to convert this house from two to three floors were rejected way back in 2001 by the local Planning Department on the grounds of it being “visually intrusive, overbearing massing not part of the existing architectural language and overlooking neighbours”. These same considerations faced Robinson Leigh Architects, whose track record of successful planning application had led to their appointment in 2013 by a client keen to find a solution to the planning impasse.There were a number of challenges for the architects, as they sought to design a scheme that would prove more successful through planning. The house is situated in St John’s Wood Conservation area, where restrictions on the character and appearance of all buildings are strictly applied. Normally any roof extension in this area would not be permitted and the house, indeed the entire mews, had been identified as an “unlisted building of merit”. Consequently the planners insisted that all new work to the house “must match existing original work in terms of choice of materials, method of construction and finished appearance in order to maintain the cohesion of the mews.The variety of roof forms in the mews, however, presented an opportunity for the architects to put forward their proposal of a flat-topped mansard roof as “a modern interpretation of the surrounding architectural precedent” said Leigh. Critically, the new mansard roof would also not add height above the general roof level of the neighbouring properties in Regent’s Mews, and thus would not be visually intrusive. The design of the three new dormer windows at the front of the house did depart from that of the dormer windows on the other mews houses though – they were square in contrast to the prevalent curved headed windows. However, given that they were really only visible from within the actual mews, the planners considered this alteration in form to be acceptable. Furthermore, the recessed glazing of the dormer windows ensured that the privacy of the occupants using the living spaces would not be compromised.The choice of materials also had to conform to the surrounding properties: the dormer windows were lead-clad, and the roof was tiled in Welsh slate, which softens its appearance and reduces the “apparent bulk of the structure.Another complication for Robinson Leigh related to the impact upon the large villas of Langford Place to the rear of the property. Vehement objections from these residents, who were concerned that the roof extension would shatter the illusion that they are set in extensive grounds led the architects to revise their proposal: the pitch of the northwest slope of the mansard roof was adjusted to a 70 degree angle in order to reduce its prominence in the views from these villas, particularly from 5 Langford Place. A second flat roof, which adjoined the house was removed, and Robinson Leigh extended the mansard roof to the parapet. This then gave the client more internal space, eliminated any overlooking issues, and created a more homogenous and symmetrical design.The architects cleverly designed both the main roof level of the mansard to be landscaped with indigenous flora in order to respect the planners’ preference for ecological biodiversity in the area as well as to attenuate water run-off.In conjunction with these structural requirements imposed on Robinson Leigh’s design of the mansard roof, unlocking natural daylight in the “dark zones” in the interior of the new storey was a key priority. Mindful of the rejection of the glazed roof proposal from 2001, which the planners had deemed to be too intrusive on the neighbours and at odds with the surrounding architecture, the architects sought to reduce the amount glazed by 50%, whilst simultaneously addressing the problem of reduced levels of natural daylight resulting from the recessed dormer windows.Robinson Leigh’s solution was to propose a more sympathetic glazing arrangement to the flat-top of the mansard roof, comprising four large fixed rooflights and a sliding over fixed rooflight from Glazing Vision, that would achieve the high specification they desired. These rooflights, pointed upwards to the sky, would maximise the amount of daylight entering the extension and bouncing off the hardwood timber, which had been used extensively, as Leigh points out, to “draw together several disparate elements of the interior design, such as the sliding walls, pocket doors and floor-to-ceiling shelving and cupboards”.Glazing Vision’s sliding over fixed rooflight was to inhabit the space immediately above the stairwell, which had also been lined in timber to subtly link the top floor with the ground floor and to help draw the eye upwards. Timber frames had also been used on the windows. As with the other four rooflights, Glazing Vision’s sliding over fixed rooflight needed to be made to a bespoke size – the architects required it to be the exact size of the stairwell, or indeed over-sized, so that the frames were not visible from below. Precision-engineered at the Glazing Vision factory in Norfolk, the special sliding over fixed rooflight was supplied in two sections, with an overall span of 2400mm and a width of 2240mm. The minimalist internal framework, finished in pure white rather than the standard grey, ensured that there were unfettered, sky-only views from the inside, thereby enhancing the impression of space and loft. Through the clear glazing of the Glazing Vision rooflight natural daylight absolutely flooded the stairwell, permeating also down to the lower floors.Given the stringent planning controls on the appearance of the mansard roof and the concerns of the vociferous neighbours, Glazing Vision’s sliding over fixed rooflight offered another invaluable benefit to Robinson Leigh. The footprint of the unit on the roof remained fixed, both open and close. This meant that there was no bulky additional furniture required, whilst the minimalist exterior framework was finished in slate grey to blend harmoniously with the Welsh slate roof tiles.No less important was the need for natural ventilation in the mansard roof extension. The architects were keen to create a venturi effect in the central core of the house and stairwell by channeling the airflow through the opening of the rooflight. The Glazing Vision rooflight, specified by Robinson Leigh to slide side-to-side rather than up and down, is electronically controlled at the touch of a button from inside the house, retracting the sliding section over the fixed section of glazing. Once the sliding section is fully retracted, there is a 50% clear opening in the rooflight, out towards the sky, thus providing superior air quality within the top floor, as well as intensifying the amount of natural daylight. An essential security feature of the Glazing Vision sliding-over fixed rooflight is that it is supplied with a manual override as standard.The design, approval and erection of the mansard roof extension took three years but Robinson Leigh have succeeded in updating a tired-looking 1980’s mews house with a new, sophisticated, modern exterior, that quietly complements the surrounding properties. The new third storey has exceeded the client’s needs for additional living space, and the clever use of rooflights has ensured the interior is light, bright and inviting.

BACKGROUNDClancy is one of the largest privately-owned construction firms in the UK. With over sixty years’ experience and a workforce of over 2,200, they have worked hard to develop a reputation as a well-run business offer essential services that help keep the UK running.CHALLENGEClancy contacted Frontier Pitts to install a Sliding Gate to secure the entrance of their prestigious HQ. As this gate would be the first and only access point to their HQ, incorporating the ‘Clancy’ branding on the gate was very important and therefore Frontier Pitts worked to incorporate the logo in the bespoke gate design.RESULTSliding Cantilevered GateFrontier Pitts popular model of Sliding Cantilevered Gate was installed with a Pedestrian Wicket Gate to the side. The made to order bespoke gate included the distinctive ‘Clancy’ logo, which was laser cut into sheet infill, positioned to the centre of the gate, and is clearly visible on approach to the headquarters. All Frontier Pitts Automatic Gates are installed in line with DHF Safety standards with a full Risk Assessment determining the most appropriate safety devices for each site’s requirements and users. Pedestrian guard rail secured the runback area of the sliding gate, with other safety devices including photocells, vehicle detector loops, safety edges and a traffic light system installed.Commenting on the installation, Clancy said:We chose Frontier Pitts as we wanted to find a company to develop a partnership with, who understood our requirements for this very custom project. We evaluated a number of suppliers and felt that Frontier Pitts truly understood how to make this gate personal to The Clancy Group with the designs and concepts provided. From start to end, we found the designers and fabricators adjusted and worked with us to make this gate just how we wanted. We also was impressed that the gate was manufactured in the UK and the feel the quality gives us the reassurance that this gate is here to stay a long time.Commenting on the installation, Sally Osmond, Brand & Development Manager said: “this is another installation of our Sliding Cantilevered Gate that we are very proud of after working closely with the client to deliver their expectations. We look forward to working with them in the future to secure their other sites.With thousands of installations around the World, the Security Sliding Gate is a cantilevered gate which requires no ground track or support across the roadway and is available to secure apertures up to 10m.The Sliding Gate is 100% duty rated – designed for continuous & frequent use. Power is supplied from a single phase 230V supply and can be connected to any access control system.All Automatic Sliding Gates should be regularly maintained, a service which Frontier Pitts also offers. A range of contracts are available with preventative planned maintenance visits and break down call outs with response times to suit your site’s requirements.

When architects Scott Brownrigg were given a brief to create a new gateway to Cambridge Science Park they knew the building had to be impressive to attract the desired high tech and research and development companies. The design features a colonnade sweeping across the front of the building echoing the curve of the spine road and a new public space. The column spacing guides occupants and visitors to the entrance – a GEZE SlimdriveSCR curved automatic sliding door. Slimdrive SCR was chosen to fit with the building BREEAM Excellent rating. The circular entrance features two sets of automatic bi-parting curved glass sliding doors, creating a lobby that minimises heat loss or gain and so helps to contribute to the building’s environmental credentialsWhen architects Scott Brownrigg were given a brief to create a new gateway to Cambridge Science Park they knew the building had to be impressive to attract the desired high tech and research and development companies. The design features a colonnade sweeping across the front of the building echoing the curve of the spine road and a new public space. The column spacing guides occupants and visitors to the entrance – a GEZE SlimdriveSCR curved automatic sliding door. Slimdrive SCR was chosen to fit with the building BREEAM Excellent rating. The circular entrance features two sets of automatic bi-parting curved glass sliding doors, creating a lobby that minimises heat loss or gain and so helps to contribute to the building’s environmental credentialsIn addition the Slimdrive SCR automatic curved sliding door provides a light and airy all-glass lobby entrance which blends into the façade and the large glass atrium; it combines high performance with unobtrusive operation. Inside the operator’s deep canopy an integrated air curtain was installed to further minimise any heat loss and maintain the aesthetics of the building. The Slimdrive SCR automatic operator also provides uninhibited access and so meets the demands of Part M, BS 8300 and EN 16005, whilst the access control system ensures security. Shortlisted for office awardsRecognising the outstanding design of the building, the Cambridge Science Park has been shortlisted for the 2023 British Council for Offices (BCO) Awards. The BCO’s primary objective is to define excellence in office space. Ross Mcwatt, associate architect at Scott Brownrigg said: "We have worked with GEZE several times, they have the same focus as we do in terms combining sustainability, accessibility and aesthetics." Richard Richardson-Derry, national specification manager at GEZE UK added: "This is an outstanding building, that meets many demands. We were delighted to play a part in creating an entrance and achieving the criteria of the brief."

IntroductionFerrari World in Abu Dhabi is the world's first Ferrari theme park. The park includes 37 different rides and attractions and features the world's fastest rollercoaster “Formula Rossa” – reaching 240 km/h in 4.9 seconds. The park has been open since 2010 and has been nominated for numerous awards. Project:Ferrari World in Abu Dhabi needed a unique solution to allow for the maintenance of rollercoaster carts. Due to restricted space, a sliding hatch was proposed to allow easy craning in and out.Products Supplied Surespan manufactured and supplied an SLHE Aluminium, thermally broken, single leaf, electrically operated, sliding roof access hatch. The hatch was a large 5400 x 4000 structural opening sliding hatch.A sliding hatch allowed maximum clear space. Operated by a 230v geared motor. The lid and upstand are filled with 50mm thick CFC and HCFC free Polyisocyanurate insulation which offers a U-Value of 0.43W/m²K.

A luxurious multi-million pound beachfront development at Carbis Bay, just outside St Ives in Cornwall, fitted the KM750 Lift & Slide Handles from our BLU 316 Marine Grade Stainless Steel Hardware Range to prevent hardware corrosion issues that a coastal location brings.With such an amazing location, the architects responsible for the development were well aware of the impact the corrosive atmosphere could have could on the look and performance of the lift and slide door sets. A hardware solution was needed that combined faultless performance with the right aesthetics and protection from corrosion. The combination of quality, performance and their look and feel set these Lift & Slide Handles apart and they quickly became the obvious choice.Manufactured from 316 Marine Grade Stainless Steel, our BLU range of door and window hardware comes with a Lifetime Guarantee. They're designed to withstand the elements and thrive even in the most corrosive environments. As a result we're seeing more architects, more developers and more quality door and window manufacturers specify hardware from our BLU 316 Stainless Steel Range, which is a testament to its quality and performance.

Product name Slimdrive SL NTType Door openers / closersDoor type suitability Sliding doorsOperation ElectromechanicalInstallation Door surround mountedGrade CommercialMax. size of door leaf 120kgOperator dimensions (mm) 70mm highPart of the Slimdrive range, the SL NT is an electronic automatic sliding door system that offers flexibility, reliability, functionality, efficiency and safety.The extremely slim design of the SL NT makes it possible for the operator to be concealed in any facade, giving architects the freedom to design stylish entrances. Extremely versatile and suitable for a wide range of applications, the Slimdrive SL NT can be used for single- or double-leafed internal or external doors. GEZE Slimdrive SL NT also benefits from quick and easy assembly and installation.The Slimdrive SL NT is an intelligent automatic door system that is perfect for busy entrances to buildings such as shopping centres, hospitals and stores - anywhere where there is a high volume of traffic and where manually operated doors are not appropriate.The Slimdrive SL NT is suitable for a variety of applications, from the simple installations to grand all-glass facades. Two or more SL NTs can be combined to provide a draught-proof lobby.Key featuresOne of the most compact sliding door operators availableOperator height only 7cmEasily integrated into almost any facadeEnvironmentally friendly due to economical use of materials and energyDimensionsOpening widths: 700 to 3000mmWeight: up to 125kg per leaf

Installation completed of 3 number MG200 sliding folding partitions with integral glazing. With this project being over budget for the client ModernGlide were able to offer our range of veneer effects laminates instead of a hard wood veneer to give a saving to the client.The sliding folding acoustic partitions were designed and installed to sepperate the busy worship and social space. This allowed for 1 larger usable room and then to be sepperated with the use of the MG200, each system were manufactured with a access passdoor. Each MG200 system offers a access door panel to get to one side of the opening to the other as standard. Our flush lever door handle has been designed to comply with the DDA regulations. Due to the high level of foot traffic within these areas the MG200 system was ideal as each panel edge being protected with a satin anodised aluminum profile. Manufactured panels have a different level of acoustic reduction, but all of them provide the kind of flexibility needed to work perfectly within any office or commercial environment following a professional installation from ModernGlide. Because there is no need for a structural head support, this makes the MG200 series perfect for smaller openings. The versatility of our sliding folding wall partitions continue through the format of slimline stacking. This means that when the wall is not in use, it will take up minimal space in your environment.

SIEGENIA's ECO PASS SKY axxent threshold is paving the way for WeberHaus.As a premium provider of prefabricated houses, WeberHaus relies on high-quality solutions. The "German Dream Home" silver prize-winning luxury villa in the "World of Living" exhibition park in Rheinau-Linx bears witness to this: its extraordinary building architecture is underlined by its exclusive furnishings and equipment, in which eleven lift and slide elements along with the hardware technology from SIEGENIA bring light and spaciousness into the building. The six elements on the ground floor with the ECO PASS SKY axxent level threshold, in particular, provide room comfort.Daily added value for the residents"The interest in large-scale elements with a passage as level as possible, convenient operation and elegant design is distinctly increasing, even among younger home owners", reported Christoph Scheuring, PORTAL product manager at SIEGENIA. WeberHaus has been meeting these expectations recently with the Premium solution for the passage from the inside to the outside: the level threshold ECO PASS SKY axxent lowers the height of the threshold, including the running rail, to 0 mm without any incline.The additional benefits of such a solution for the producer of prefabricated houses, which has been relying on SIEGENIA for large-scale elements for a number of years now, is obvious: "The ease of use achieved by the reduction of the difference in level between the inside and outside to zero generates a daily added value for the residents," explained Daniel Eckstein, head of construction planning at WeberHaus.A solution with an elegant appearance awarded the Red Dot prizeThe elegant design of ECO PASS SKY axxent is also a persuasive argument for home owners. This begins with the optical adaptation of the threshold to the frame material. Moreover, the design of the fixed sash is optically appealing: by saving on the profiles, the portion of glass is maximised to such an extent that the glass is flush with the floor surface. And last but not least, the outside appearance is harmonious. There the elegant design of the grille for the threshold drainage flows seamlessly into the drainage gutter. The threshold therefore won the renowned Design Award „Red Dot: Best of the Best 2020“ for its trailblazing design. ECO PASS SKY axxent can also be convincing in terms of security with burglar resistance up to RC3.Technically mature, ECO PASS SKY axxent also exhibits its strengths with regard to sill installation. SIEGENIA cooperates with the drainage specialist Gutjahr to guarantee a specialised high-quality solution, both for design harmonisation of the threshold and drainage gutter. From the perspective of Daniel Eckstein, this is an advantage: "Beside the attractive, uniform, appearance, this allows us to achieve an optimum coordination of the drainage system and the connecting system with regard to the designing of the exterior area."Motorised operation for ease of use The motorisation of large-scale elements and their integration in Smart Home systems will play an ever increasing part in the future according to the estimation of the WeberHaus expert. „The motorised drive of lift and slide doors is a significant feature in the view of home owners: large window elements are heavy and consequently can only be moved with the application of force. Whereas, they can be really difficult to stop during the sliding process“, explained Daniel Eckstein. He therefore had one of the particularly large elements of the villa equipped with the motorised drive DRIVE axxent HSA smart from SIEGENIA. The fully automatic, partially concealed drive system has an elegant appearance and is convincing due to its concealed lift drive and its flat, discreet control knob. Operation is convenient: the sash can be opened and closed either by using the control knob, per radio remote control or via the SIEGENIA Comfort app.

A Rundum Original sliding garage door spanning 8m wide and 2.2m high was integrated within the new designs by BWP Architects for a major property renovation, transforming a house which had evolved in an uncoordinated and poorly designed way. The door provides access to a large garage space below the property’s garden level and its shape coordinates elegantly with a car turntable installed immediately in front and surrounding landscaping.The owner tasked BWP with bringing new life to the property which has many original features. Undoing of previous conversion and extension work was necessary to enable the rebuilding of the residential property to a significantly higher standard, complete with the feature garage. An existing detached garage to the rear was partially demolished and converted to create a private formal rear courtyard. The replacement curved garage is a stunning visual element, with the new automated Rundum Original door’s high quality Larch complemented by bronze coloured bespoke balustrading to add a dramatic and artistic feature to the access stair and upper courtyard over the garage.The Rundum Original side sliding door is automated using two door mounted MZ4 drives which are custom made to automate these bespoke doors. These motors allow the door to traverse the curving tracks smoothly and quietly as required for this project. The door was designed in conjunction with Rundum Meir’s UK team before being hand-crafted by its garage door experts. Every door is made to order to the highest standards using responsibly sourced materials and installed by Rundum Meir to provide an end-to-end service.Danesch Missaghian, Director of Rundum Meir (UK) said: “Not only is this exciting project completed using very high specification products throughout, but it is also designed superbly with the architects using a curved garage door in an interesting way that maximises vehicular access. We are delighted with the contribution our door has made to the success of this project.”In addition to a range of different timber species, bespoke Rundum Original side sliding garage doors can be manufactured in high strength extruded aluminium and finished in any RAL colour. This makes these garage doors suitable for any domestic, commercial or public application, with the scope for architects to think differently about how the space for a garage can be integrated into the wider building design.

P C Henderson's Rustic 80 sliding barn door hardware has recently been specified for a home renovation of a period property in Kent. The 11 month renovation included a complete rewire, full house re-plaster, a full damp-proof course, new heating and plumbing system and a new kitchen and bathroom. The couple also required some sliding door hardware for the properties bedroom and bathroom doors. Our Rustic sliding barn door hardware was identified as the best solution for the project due to its beautifully crafted barn style hangers and rustic effect.

Henderson’s sliding door hardware systems were specified by Penton Architects for the central dining space and garage of the architects’ own rural new build. Adam Penton commented: “The large sliding doors to the central dining space utilise P C Henderson’s Lift and Slide Base System which was specified for its performance and ability to be housed into a bespoke glazed timber screen and cill system.” The dining room doors open up the side of the house and are used daily during the summer months for ventilation and access to external terracing to create an indoor / outdoor experience.

The architectural consultant required sliding gear that was capable of moving two large gates with a weight of 3500kg. Our Straight Sliding 307 hardware was specified for its unique product capacity of 2000kg. We worked closely with the fabricator to come up with a solution to meet the weight capacity of the large gates and were able to find a solution by merging four hangers into one to effortlessly carry the gates. Due to their large size, the fabricator installed the 307 sliding hardware, together with the gates, on-site, utilising; 11 tracks, 18 hangers, 60 brackets and 10 stops.

The new thermally broken sliding roof hatch opens horizontally on fixed or telescopic rails. The hatch features the following key points: Thermally Broken Lid & Upstand Fixed or Telescopic Rails ‘Lift-Off’ Unseated Opening, ensures the hatch is sealed and secure when closed. Self Sealing Double Seals 0.43 W/m²K U-value Perfect for manual operation, the sliding cover easily and smoothly opens. Brush seals around the front and side ensure that no roof debris can interfere with the mechanism and the external fixed rail provides enhanced support for larger sliding covers.

Leading partitioning specialist, Style, has launched a new glass sliding wall solution for balconies and terraces (BSW). Transforming a balcony into functional space, glass panels are used to enclose the area, creating a barrier against weather and noise without impeding the view. On fine days, the upper section of the glass panels can be neatly folded and stacked to one side, allowing people to sit out and enjoy the sunshine.For terrace rooms that open straight out into a garden or external seating area, Style’s new glass sliding wall allows the boundary between the two spaces to be easily removed on sunny days, whilst successfully combining weather protection with uninterrupted views of the outside during inclement weather.With a discrete guidance track that can be fitted flush to the floor, the BSW system creates a truly a streamlined aesthetic. “This is an exciting addition to our portfolio of glass moveable, folding and partitioning walls,” said Mark Cowley, who heads up the glass solutions division at Style. "With space at a premium, it makes sense to extract the maximum functionality from what is available.”“Our sliding-folding glass wall system brings the outdoors in, effectively expanding the living space in residential homes. In commercial settings, such as restaurants for example, the BSW can be used to increase capacity by making use of a balcony or external area that would otherwise only be enjoyed in good weather.” Making for a welcoming environment, even when a terrace room or balcony is entirely enclosed by the glass panels, air still circulates internally thanks to tiny, 3mm gaps between that provide continuous ventilation. Any condensation is quickly filtered outside thanks to unobtrusive drainage vents and guttering.Fitted with a sophisticated roller system, the individual glass panels also incorporate autonomous pivot point identifiers, ensuring smooth and effortless manoeuvrability every time.Ideal for residential and hospitality settings, the BSW system also offers opportunities for sports clubs, retail outlets and commercial offices, wherever a more enjoyable experience could be offered by opening-up an internal area to incorporate an outdoor space.

Introducing the First LPS1175 Bi-parting pair of Sliding GatesA busy year of Research & Development continues with the introduction of our latest LPS1175 Intruder Resistant product.The first Security Gate Frontier Pitts enhanced to meet the LPCB LPS1175 standard was our LoTracker model back in 2017Since then we have enhanced the rest of our Security Gates models to achieve the LPS1175 Security ratings. However in 2020 one of customers tasked us to develop a security rated bi-parting pair of Sliding Gates to secure larger apertures for sites such as Datacentres, Haulage and Logistics. Frontier Pitts worked closely with LPCB during the lockdown months, co-ordinating safe, socially distanced testing in our factory, to ensure our R&D program continued to produce products to meet our clients requirements.Now the LPS1175 Platinum Bi-parting pair of Sliding Gates can secure clear apertures up to 14m. A first for the LPCB LPS1175 market!

ASSA ABLOY Entrance Systems' expertise in transportation applications made us an ideal partner for the Doncaster Transport Interchange project. In working together with the project’s engineers, automatic sliding door systems were determined to be the optimal solution for the bus depot due their reliability and safety. The clean lines of the ASSA ABLOY sliding doors also complemented other elements of the broader French gate Centre urban renewal project, which includes an integrated train station and car park for visitors to the nearby city centre, in addition to the shopping mall.

The non-profit organization Living Architecture has realised four special holiday homes across England, each one is an extraordinary example of contemporary architecture, designed by leading architects. The most spectacular of the projects is the ‘Balancing Barn’ in Suffolk (Uk), designed by the Dutch bureau MVRDV. In the 30-metre long house, which juts out 15 metres over the edge of a rise, Reynaers CP 155-LS (Lift & Slide) was used for the large sliding windows. The large protruding section meant that it was possible to place another large window in the floor as a complement to the architectonic spectacle.

Introducing the next generation of sliding systems. MasterPatio is a high insulation and high performance lift-slide system with minimalistic look and clean design, down to the details. The system combines top thermal performance with slim sightlines and a maximum element height of 3.7 m.

Individual or hinged panel single glazed sliding system with the option of with crittall bars. This single glazed sliding system can achieve 34dB.The benefit of our MG900 panels is that they work in the same way as conventional movable walls and can be either single or double point suspension. With the slim back painted border you have clear view visual lines. This allows a superior light flow around the office, cost-effective installation and flexibility in the work environment. Plus the simple fact that they look elegant and classy. Not only these, but they also offer exceptional sound reduction allowing for privacy to be had amongst clients or for important internal meetings.The MG900 glazed system is a 35mm thick panel that can be incorporated into your standard fixed glazed partitioning system.So this unique 35mm thickness gives endless designs and layout options.Furthermore, the aluminium frame can be coloured to your choice to match your design or branding needs. These panels retain a room’s spacious sense of proportion and maximise light and clear viewing lines. Truly a magnificent office aesthetic.MG900 Key FactsAcoustic reduction from 34dBSlimline 35mm thick panelsTop hung with a shallow 4mm floor guidePanel widths 450mm to 1200mmHeight up to 3000mmPanel border finish any chosen RAL finishCrittall bar glazing designs to suit your design needs

The project was to create a partitioned living space with the requirements of ample storage, traditional style, integrated LED lighting and a sliding door mechanism. After seeking advice from our Holland office, Ralpine Designs decided that our Husky 100 sliding door hardware was the right project for the job. Using a library and display unit, the living room and dining room could be separated into two rooms or opened up as one big room when required. The system was used to hold two biparting wooden doors, utilising a face fixed aluminium track for added quality.

Project:The construction of luxury offices and apartments required a bespoke access solution to the roof.ProductSurespan designed and manufactured a boxed glazed sliding rooflight with a glazed vertical upstand.The sliding lid was operated electrically via concealed 24v DC actuators and a push-button switch. The 35.5mm sealed double glazed unit comprises of Pilkington 6mm toughened K polished all-round outer pane, a 20mm Warm Edge silver spacer bar that is argon filled, and a Pilkington 9.5mm toughened & laminated inner pane. The sealed glazed unit has a U-Value of 1.5 W/m²K.Features:Operated electrically via concealed 24v DC actuators35.5mm sealed double glazedPilkington 6mm toughened K polished20mm Warm Edge silver spacer barPilkington 9.5mm toughened & laminated inner pane. U-Value of 1.5 W/m²K.

Surespan manufactured a double-glazed sliding access hatch for use in a private residential apartment in London. Product2640 (103?) x 2020mm (79?) hatch was electrically operated via a key switch for easy operation and allowed access to the roof providing views across the London skyline. The sliding cover was finished in grey external polyester powder coating with a white internal finish. The 35.5mm sealed double glazed unit comprised of Pilkington 6mm toughened K polished all-round outer pane, 20mm Warm Edge silver spacer Bar argon filled, Pilkington 9.5mm toughened & laminated inner pane, divided into two panes.

ProjectSurespan designed and manufactured these huge electrically operated sliding glazed roof hatches also provide free airflow of 7m² for smoke ventilation!These bespoke designs were part of a redevelopment on Great Portland Street in London. The covers were 4610 x 1955mm and featured an electrically driven opening motor.Product: The covers provide 7m² free airflows (As it is sliding there are no obstructions to the ventilation) according to approved document B (fire safety) paragraph 5b diagrams C.7.The glazing features laminated and heat-strengthened low iron glass to L40.A further fixed rooflight was also supplied to the size of 4935mm x 1955mm, the thermally broken multi-pane rooflight provides natural daylight

Project:Surespan designed and manufactured a massive Biomass access hatch for a fuel plant in Coatbridge, Scotland.ProductBiomass Cover features an opening 3500 (137?) x 4000 (157?) with a sliding cover features fixed external rails and electric operation.A further two sliding covers were supplied sized 2500 x 4000 and 1500 x 4000mm

Project:Surespan designed and manufactured a massive Biomass access hatch for a fuel plant in Coatbridge, Scotland.ProductBiomass Cover features an opening 3500 (137?) x 4000 (157?) with a sliding cover features fixed external rails and electric operation. A further two sliding covers were supplied sized 2500 x 4000 and 1500 x 4000mm

Project: Surespan designed and manufactured these huge electrically operated sliding glazed roof hatches also provide free airflow of 7m² for smoke ventilation!These bespoke designs were part of a redevelopment on Great Portland Street in London. The covers were 4610 x 1955mm and featured an electrically driven opening motor.Product:The covers provide 7m² free airflow (As it is sliding there are no obstructions to the ventilation) according to approved document B (fire safety) paragraph 5b diagrams C.7.The glazing features laminated and heat-strengthened low iron glass to L40.A further fixed rooflight was also supplied to the size of 4935mm x 1955mm, the thermally broken multi-pane rooflight provides natural daylight

Designed and Manufactured by Simplicity Timber Solutions Accoya was chosen as the ideal wood for these curved folding sliding doors in a project called The Hermitage. Accoya was selected due to its aesthetic appearance and ability not to shrink or swell during seasonal weather changes. Keep a look out as The Hermitage project is set to be featured in the December 2016 issue of Grand Designs.

The Platinum Sliding Gate joins the first Bi-folding Speed Gate to withstand forcible attack and be accredited to LPS1175 Security Rating 2 & 3 in the World. Secured by Design approved

Automatic sliding doors provide patient comfort at outstanding healthcare facilityThomas Audley Ward at Homerton Hospital, London - The trust operates acute services from a single site: Homerton University Hospital, which opened in 1986. Based on an aggregation of ratings across all of the core services provided from the hospital, the hospital has been rated by Care Quality Commission as ‘Outstanding’.Architect – Hunters ArchitectsProduct – SL500 bi-parting doors in slim-eco profiles with fixed side screens of up to 8 panels covering 6.7m on 4 separate bays.The works encompass a full ward refurbishment comprising of layout changes, floor, wall and ceiling finishes, sanitary appliances, mechanical and electrical installations, fixtures and fittings renewal and internal doors.Working alongside the project lead architect, we assisted with the design to create 4 new ward entrance screens, to assist with reducing noise and air pollution, creating a more welcoming and comfortable patient environment. Our slim-eco door profiles were chosen and also provided with our unique TightSeal system, minimising any gaps around the doors. In addition to the door profiles, directional activation units were installed, contributing even further to eliminate unnecessary opening cycles.

Island Rest, in the Isle of Wight, is designed to be a contemporary family escape offering unique views across the Solent – a 20-mile stretch of water, while equipping occupants with everyday functionality. There are many layers to Island Rest which enable the building to blend into and celebrate its beautiful environment. Glazing is a key part of this - Hi-Finity is utilised to create a variety of features, from full-height windows which frame the spectacular views, through to large sliding doors which open up living spaces onto a courtyard and landscaped gardens.

Bloot Architecture, a concept-driven architectural practice located in the Netherlands, has recently specified P C Henderson’s Husky 100 sliding door system for the renovation of a luxury villa. After falling in love with the beautiful and picturesque surroundings of the National Park Veluwezoom in Holland, the architecture firms client purchased a dilapidated 1950’s villa in order to live in their dream location. What ensued was a sustainable refurbishment and extension project – key features included the creation of open plan living, full of natural light, with the inclusion of a flexible office space built on via an extension.

The MG900 is an ideal solution to any project, where it can pitvot, slide or interlock to form a solid glazed partition.Furthermore, the aluminium frame can be coloured to your choice to match your design or branding needs. These panels retain a room’s spacious sense of proportion and maximise light and clear viewing lines. Truly a magnificent office aesthetic.The benefit of our MG900 panels is that they work in the same way as conventional movable walls and can be either single or double point suspension.With the slim back painted border you have clear view visual lines. This allows a superior light flow around the office, cost-effective installation and flexibility in the work environment.Plus the simple fact that they look elegant and classy. Not only these, but they also offer exceptional sound reduction allowing for privacy to be had amongst clients or for important internal meetings.

A four-storey underground car park needs to meet enormous fire protection requirements. Preventive fire and smoke protection and fully functional escape routes and emergency exits were top of the list when planning the doors and barriers. T90 fire and smoke protection doorsets were used for highly frequented areas with a higher risk of fire and the gallery and escape routes between the individual fire compartments were fitted with single and double-leaf T30 doorsets with round glazing. Access points to the individual levels were equipped with T30 sliding doors and T30 sectional doors.

Onyx Apartments is an 11-storey building located on the Regent’s Canal banks, offering 117 bespoke homes. The development was designed as a modern, elegant and professional living environment. Comfort and safety were top priorities in bringing this project to life and Reynaers products were used to realise those aims. CS 86 ‘High Insulated’ aluminium window system offers an energy-efficient option, and CP 155 ‘Lift and Slide’ aluminium door system creates maximum glazed areas while also maintaining comfort. Onyx Apartments is a great example of combining elements of luxury and practicality, bringing a fresh perspective to the area.

A MG500 flush glazed sliding folding system completed project in Coventry. Panel profiles finished in a bronzed aluminum to match the project design. Each panel applied with crittall bars and a reeded glass film, these panels make a statement. MondernGlide were involvement in the project via Planet and it’s been a pleasure working in helping with the design and construction works onsite. The redevelopment project was split into 2 different phases. Phase 1 was all about the sympathetic refurbishment of the main B1 auditorium and associated public spaces. It is about retaining and enhancing the historic nature of this space, whilst refurbishing many of the tired and worn finishes and fittings to completely refresh the space The benefit of the MG500 is that we require no structural support within the ceiling meaning this product can be installed anywhere. With the slim back painted border you have clear view visual lines allowing a superior light flow around the office, cost-effective installation, flexibility in the work environment as well as the simple fact that they look elegant and classy.

77 spectus vertical sliding windows have been manufactured and installed in the first phase of a new 900 home development in holbeach, lincolnshire.
