Zenturo Gabion Wall - Metal Mesh Fence Panel
Compare variants

Application

  • Residential developments, gardens and communal areas.
  • Public buildings.
  • Parks and green spaces.

Description

From a closed partition to a garden feature, these panels can be used for different purposes and in various configurations that offer privacy and security.


Features and benefits:

  • The panels can be filled with a variety of natural materials that enable the production of walls and boundaries that complement their environment.
  • Welded from round galvanized wires, it creates a strong character to any garden or green space by combining varying mesh sizes and the double and alternating horizontal wires.
  • Offers many possibilities for personalization.
  • Climbing plants and sedums feel at home on the strong grid support. The panel is also highly suited as a decorative garden element in the form of a standalone garden panel or as a wall panel.
  • The panels can be filled with sedums to create a 'living wall' or any number of decorative natural items such as stones, pebbles, tree bark, branches etc.
  • Ten year manufacturer's guarantee.

General information

Color

Green

Grey

White

Black

Finish

Galvanised finish

Shape

Rectangular

Square

WarrantyDescription

Ten years

Uniclass 2015

Pr_20_85_28_36 Galvanized wire gabion cagesPrimary

CAWS

D41/210 Gabions

Specification data - Galvanized wire gabion cages Enhanced data

Product Reference

Zenturo Super

Panel

  • Double alternating horizontal welded round wires.
  • Galvanized and polyester plastic coated.
  • Horizontal wire diameter: 5 mm.
  • Vertical wire diameter: 4.15 mm.
  • Mesh: 100 x 50/ 50 x 50 mm.
  • Colour: Anthracite grey BF 7016M.

Accessories

None.

Spacers.

Zenturo spider clips.

Width

2000 mm.

Special order.

Consult manufacturer and insert requirement.

Posts

  • Rectangular, 120 x 40 mm.
  • M6 inserts on both sides.
  • Galvanized and polyester plastic coated.
  • Zenturo/ Zenturo Super panels to be mounted on these posts using specific spider clips.
  • Colour: Anthracite grey BF 7016M.
  • Consult manufacturer's literature if used as a filled wall.

Standard

ISO 16120-2, EN 1179, ISO 22034-2, EN 10223-7, ISO 9227, ISO 16474-3.

Digital objects

Platform Compatible Version Certified to
IFC
-

1

1.3
Revit

Revit 2016

1

1.3
Download now from NBS National BIM Library
