Washing Trough Lh Outlet 4 Person X4 Th - Wash trough
Description

Stainless steel, four person washing trough with four tap holes, 1.5” waste and no overflow. Available with a left or right hand outlet. Suitable for commercial, education, healthcare, security, hotels and leisure applications.

General information

Color

Stainless steel

Finish

Satin polish finish

Material

Stainless steel type 304 to EN 1 4401 or SS2333, AFNOR Z 6 CN 18-09, BS 304S31

Size

370 x 2400 x 155 mm

WarrantyDescription

25 years Ceramic products (excluding accessories and fittings), steel and acrylic baths

Uniclass 2015

Pr_40_20_96_99 Wash troughsPrimary

CAWS

N13/346 Washing troughs

Specification data - Wash troughs

Product Reference

PS9319SS - Stainless Steel Washing Trough

Left hand outlet.

PS9320SS - Stainless Steel Washing Trough

Right hand outlet.

Water supply fittings

SF2152CP-Sola 1/2 Non-Concussive Taps (pair)

SF2201CP-Sola 1/2" Pillar Taps X Head (pair)

SF2401CP-Sola 1/2" Lever Action Taps (pair), HTM64-TP

SF2104CP-Sola Temperature Controlled Non-Concussive Monobloc HTM64-TPP1

SF2151CP-Sola 1/2 Non-Concussive Tap (single, hot & cold indice)

Leg supports

Not required

PS4064SS

Pair.

Standard product features

Material:

Stainless steel grade 304 (EN 1.4301 or SS 2333; AFNOR Z 6 CN 18-09; BS 304S31). 1.2 mm thickness.

Size:

2400 x 370 x 150 mm.

Finish:

Natural.

Product Options

Fixings:

Wall fixings (not supplied).

Digital objects
Platform Compatible Version Certified to
Revit

Revit 2016

1

1.3
Download now from NBS National BIM Library
