Type TK Round
Compare variants

Application

Suitable for use in hotel facilities, food service areas and the private sector.

Description

Round telescope umbrella parasol with keder profile.


Features and benefits:

  • Cover consists of individual membrane segments, meaning smaller sections can be replaced if required to help reduce costs. The segments are equipped on the sides with a pole, which will be inserted into the keder rail and fixed with bolts.
  • Struts are visible from the top of the screen, as the membrane is anchored within the struts and not stretched over them.
  • Can be combined with accessories such as LED lamps, sound and heating.
  • Can be used in exposed, windy locations.
  • Roofing sheets are fade, light and water resistant, as well as tear and abrasion resistant.
  • All materials are water and corrosion-resistant, and fixing screws are rust-resistant.
  • All components are replaceable.
  • Cabling is housed within the central mast.
  • Good wind resistance.
  • Simple installation.
  • Telescopic pole.

General information

Shape

Circle

Color

Various (dependent on covering).

Black

White

Silver

Finish

Powder-coated

Polyester powder-coated (PPC) 80 μm.

Material

Aluminium

Frame.

PVC

Roof covering.

PTFE

Roof covering.

Size

8000 x 5270 mm

5000 x 4450 mm

7000 x 5570 mm

6000 x 4500 mm

Uniclass

Pr_20_65_78_58 Open sided sheltersPrimary

CAWS

B91/385 Shelter

Specification data - Open sided shelters Enhanced data

Shelter description

Round with telescope umbrella and keder profile.

Dimensions

-

Plan size

5000 x 5000 mm.

Height

Height: Closed: 4450 mm, open: 3200 mm.

Frame

-

Material

Aluminium.

Finish

Powder coated.

Colour

Black RAL 9005.

Silver RAL 9006.

White RAL 9010.

Standard.

Roof covering

MDT-tex® 300 (PTFE).

MDT-tex® 450 (PTFE).

MDT-tex® 700 (PTFE).

MDT-tex® 480 (PVC).

MDT-tex® 680 (PVC).

Openings

-

Doors

Can be integrated if cloth walls are specified, consult manufacturer.

Windows

Can be integrated if cloth walls are specified, consult manufacturer.

Integral services

Not required.

Lighting.

Rainwater drainage

Not required.

Rain gutter to connect adjoining umbrellas.

Accessories

Not required.

Cloth side walls (with integrated windows/ doors as specified).

Event platform.

Heaters.

MDT Flex-Bar.

Mobile ground flooring.

Protective sleeve with telescopic pole.

Speakers.

Valances.

Wind walls.

Roof covering colour options

Various (dependent on covering). Consult manufacturer.

Wind resistance

Up to 100 km/h.

Printing options

Not required.

Screen print.

Spokes construction

Rectangular aluminium bars of 40 x 20 x 2 mm-60 x 30 x 3 mm.

Construction

Aluminium profile of 150 x 5 mm (aluminium telescope 80-100 x 5 mm).

Distance (spokes to ground)

5 m Diameter: Closed: 1900 mm, open: 2400 mm; 6 m Diameter: Closed: 1470 mm, open: 2600 mm; 7 m Diameter: Closed: 1900 mm, open: 2600 mm; 8 m Diameter: Closed: 1270 mm, open: 2600 mm.

Anchoring

In ground tube with foldable adapter.

Operation

Hand crank.

Digital objects

Platform Compatible Version Certified to
IFC
-

1

2.1
Revit
-

1

2.1
Download now from NBS National BIM Library
