Thermal Insulation Board
Thermal insulation board for use with underfloor heating.
Thermal insulation board comprising of a rigid foam core, reinforcement mesh and a cementitious hard coat. For use with underfloor heating, to reduce downward heat loss and improve energy efficiency. Available in various thicknesses from 4 mm.
Size | 600 x 1200 mm |
Material | High density extruded polystyrene Technical properties Compressive strength: 300 kPa Thermal conductivity: 0.033 W/mK Water absorption by volume (to BS EN 12087): 0.6% Core density: 36 kg/m³ Temperature range: -50 to +75°C Fire performance: Class 0 |
Uniclass 2015 | |
CAWS | K11/115 Battened plywood floating floor K11/125 Battened particleboard floating floor K11/145 Battened cement-bonded particleboard floating floor K11/225 Particleboard floating floor K11/245 Cement bonded particleboard floating floor K11/25 Particleboard floating floor K11/295 Floating floor system K11/60 Board |
Product Reference | Thermal Insulation Board |
Size | 600 x 1200 mm |
Thickness | 4 mm3.75 W/m²K U-value. 6 mm3.05 W/m²K U-value. 10 mm2.23 W/m²K U-value. 12.5 mm1.91 W/m²K U-value. 20 mm1.33 W/m²K U-value. 30 mm0.95 W/m²K U-value. 40 mm0.74 W/m²K U-value. 50 mm0.60 W/m²K U-value. 60 mm0.51 W/m²K U-value. 70 mm0.44 W/m²K U-value. |
Standard product features | Material:
Weight:
|
