Description

Partitioning systems incorporating Megadeco gypsum board, fixings, frame and finishing products. Suitable for use across many construction sectors, including commercial, residential, education and health. They offer a simple, lightweight, durable and versatile means of dry wall construction.

General information
Specification data
Product Reference

Siniat Megadeco Partition Systems

Partition type

AMP 004: Acoustic C Stud Partition

System weight: 30 kg/m²; Thickness: 100 mm; Fire performance: 60 minutes; Strength duty: Severe; Acoustic performance: 48 dB sound reduction.

AMP 138: Acoustic C Stud Partition

System weight: 31 kg/m²; Thickness: 120 mm; Fire performance: 60 minutes; Strength duty: Severe; Acoustic performance: 52 dB sound reduction.

AMP 140: Acoustic C Stud Partition

System weight: 27 kg/m²; Thickness: 100 mm; Fire performance: 60 minutes; Strength duty: Severe; Acoustic performance: 53 dB sound reduction.

AMP 141: Acoustic C Stud Partition

System weight: 40 kg/m²; Thickness: 120 mm; Fire performance: 60 minutes; Strength duty: Severe; Acoustic performance: 54 dB sound reduction.

AMP 142: Acoustic C Stud Partition

System weight: 53 kg/m²; Thickness: 150 mm; Fire performance: 90 minutes; Strength duty: Severe; Acoustic performance: 60 dB sound reduction.

RMP 001: C Stud Partition

System weight: 27 kg/m²; Thickness: 100 mm; Fire performance: 60 minutes; Strength duty: Severe; Acoustic performance: 40 dB sound reduction.

RMP 003: C Stud Partition

System weight: 27 kg/m²; Thickness: 100 mm; Fire performance: 60 minutes; Strength duty: Severe; Acoustic performance: 49 dB sound reduction.

RMP 009: C Stud Partition

System weight: 43 kg/m²; Thickness: 120 mm; Fire performance: 120 minutes; Strength duty: Severe; Acoustic performance: 52 dB sound reduction.

RMP 011: C Stud Partition

System weight: 44 kg/m²; Thickness: 120 mm; Fire performance: 120 minutes; Strength duty: Severe; Acoustic performance: 56 dB sound reduction.

RMP 017: C Stud Partition

System weight: 57 kg/m²; Thickness: 206 mm; Fire performance: 90 minutes; Strength duty: Severe; Acoustic performance: 57 dB sound reduction.

RMP 038: C Stud Partition

System weight: 55 kg/m²; Thickness: 200 mm; Fire performance: To BS 476-22: 120 minutes; to BS EN 1364-1: 90 minutes; Strength duty: Severe; Acoustic performance: 63 dB sound reduction.

RMP 050: C Stud Partition

System weight: 40 kg/m²; Thickness: 120 mm; Fire performance: 60 minutes; Strength duty: Severe; Acoustic performance: 56 dB sound reduction.

RMP 062: C Stud Partition

System weight: 29 kg/m²; Thickness: 176 mm; Fire performance: 60 minutes; Strength duty: Severe; Acoustic performance: 42 dB sound reduction.

RMP 127: C Stud Partition

System weight: 27 kg/m²; Thickness: 120 mm; Fire performance: 60 minutes; Strength duty: Severe; Acoustic performance: 42 dB sound reduction.

RMP 128: C Stud Partition

System weight: 27 kg/m²; Thickness: 120 mm; Fire performance: 60 minutes; Strength duty: Severe; Acoustic performance: 50 dB sound reduction.

RMP 130: C Stud Partition

System weight: 45 kg/m²; Thickness: 140 mm; Fire performance: 90 minutes; Strength duty: Severe; Acoustic performance: 57 dB sound reduction.

RMP 138: C Stud Partition

System weight: 27 kg/m²; Thickness: 120 mm; Fire performance: 60 minutes; Strength duty: Severe; Acoustic performance: 51 dB sound reduction.

RMP 140: C Stud Partition

System weight: 54 kg/m²; Thickness: 150 mm; Fire performance: 90 minutes; Strength duty: Severe; Acoustic performance: 58 dB sound reduction.

System height

As drawing

Insert reference.

Jointing

Insert requirement(s) from manufacturer's literature.

Sealer

GTEC Drywall Sealer

Ivory, pre-decoration coat for plasterboard.

GTEC Universal Sealer

For use on plasterboard prior to painting for improved whiteness and covering power.

Accessories

None

GTEC V-Brace

For RMP 038 only, 1500 mm centres.

Standard product features

Strength duty rating (to BS 5234-2):

Severe.

Megadeco Board:

  • Material: Aerated calcium sulfate di-hydrate with fillers and fibres enclosed inside a white pre-sealed paper with bound edges. Core and papers are bonded with starch. PVA edge glue.
  • Size (w x l): 1200 x 2400–3000 mm.
  • Nominal weight: 11–13 kg/m².
  • Thermal resistance (R-value): 0.05–0.06 m²K/W.
  • Thermal conductivity: 0.25 W/mk.

GTEC Intumescent Acoustic Sealant:

Perimeter sealing to restrict smoke, sound and fire penetration. Ensures system performance.

GTEC Corner and Edge Beads:

Provides corner and edge reinforcement.

GTEC Socket Pad:

Maintains acoustic and fire integrity at sockets.

GTEC Insulation Hold:

Secures insulation to prevent slump.

Fixings:

GTEC Self-Tapping Drywall Screws.

Product Options

Partition type:

- AMP 004: Acoustic C Stud Partition:

  • Facing outer layers: One 15 mm-thick Megadeco Board both sides.
  • Studs: Single GTEC AS70Rx Acoustic C studs at 600 mm centres.
  • Insulation: 50 mm-thick, 16 kg/m³ density glass mineral wool (supplied by others).
  • Fire performance (to BS 476-22 and BS EN 1364-1): 60 minutes.

- AMP 017: Acoustic C Stud Partition:

  • Facing inner layers: One 15 mm-thick GTEC Fire Board both sides.
  • Facing outer layers: One 15 mm-thick Megadeco Board both sides.
  • Studs: Single GTEC AS146Rx Acoustic C studs at 600 mm centres.
  • Insulation: 100 mm-thick, 10 kg/m³ density glass mineral wool (supplied by others).
  • Fire performance (to BS 476-22 and BS EN 1364-1): 120 minutes.

- AMP 138: Acoustic C Stud Partition:

  • Facing outer layers: One 15 mm-thick Megadeco Board both sides.
  • Studs: Single GTEC AS90Rx Acoustic C studs at 600 mm centres.
  • Insulation: 75 mm-thick, 16 kg/m³ density glass mineral wool (supplied by others).
  • Fire performance (to BS 476-22 and BS EN 1364-1): 60 minutes.

- AMP 142: Acoustic C Stud Partition:

  • Facing inner layers: One 15 mm-thick GTEC dB Board both sides.
  • Facing outer layers: One 15 mm-thick Megadeco Board both sides.
  • Studs: Single GTEC AS90Rx Acoustic C studs at 600 mm centres.
  • Insulation: 75 mm-thick, 16 kg/m³ density glass mineral wool (supplied by others).
  • Fire performance (to BS 476-22 and BS EN 1364-1): 90 minutes.

- RMP 001: C Stud Partition:

  • Facing outer layers: One 15 mm-thick Megadeco Board both sides.
  • Studs: Single GTEC CS70Rx C studs at 600 mm centres.
  • Fire performance (to BS 476-22 and BS EN 1364-1): 60 minutes.

- RMP 003: C Stud Partition:

  • Facing outer layers: One 15 mm-thick Megadeco Board both sides.
  • Studs: Single GTEC CS70Rx C studs at 600 mm centres.
  • Insulation: 25 mm-thick, 16 kg/m³ density glass mineral wool (supplied by others).
  • Fire performance (to BS 476-22 and BS EN 1364-1): 60 minutes.

- RMP 004: C Stud Partition:

  • Facing outer layers: One 15 mm-thick Megadeco Board both sides.
  • Studs: Single GTEC CS70Rx C studs at 600 mm centres.
  • Insulation: 50 mm-thick 16 kg/m³ glass mineral wool (supplied by others).
  • Fire performance (to BS 476-22 and BS EN 1364-1): 60 minutes.

- RMP 009: C Stud Partition:

  • Facing inner layers: One 12.5 mm-thick GTEC Fire Board both sides.
  • Facing outer layers: One 12.5 mm-thick Megadeco Board both sides.
  • Studs: Single GTEC CS70Rx C studs at 600 mm centres.
  • Fire performance (to BS 476-22 and BS EN 1364-1): 120 minutes.

- RMP 011: C Stud Partition:

  • Facing inner layers: One 12.5 mm-thick GTEC Fire Board both sides.
  • Facing outer layers: One 12.5 mm-thick Megadeco Board both sides.
  • Studs: Single GTEC CS70Rx C studs at 600 mm centres.
  • Insulation: 25 mm-thick, 16 kg/m³ density glass mineral wool (supplied by others).
  • Fire performance (to BS 476-22 and BS EN 1364-1): 120 minutes.

- RMP 017: C Stud Partition:

  • Facing inner layers: One 15 mm-thick GTEC dB Board both sides.
  • Facing outer layers: One 15 mm-thick Megadeco Board both sides.
  • Studs: Single GTEC CS146Rx C studs at 600 mm centres.
  • Insulation: 25 mm-thick, 16 kg/m³ density glass mineral wool (supplied by others).
  • Fire performance (to BS 476-22 and BS EN 1364-1): 90 minutes.

- RMP 038: C Stud Partition:

  • Facing inner layers: One 15 mm-thick GTEC dB Board both sides.
  • Facing outer layers: One 15 mm-thick Megadeco Board both sides.
  • Studs: Twin GTEC CS50Rx C studs at 600 mm centres.
  • Insulation: 25 mm-thick, 16 kg/m³ density glass mineral wool (supplied by others).
  • Fire performance: To BS 476-22: 120 minutes; to BS EN 1364-1: 90 minutes.

- RMP 050: C Stud Partition:

  • Facing inner layers: One 9.5 mm-thick GTEC Standard Board both sides.
  • Facing outer layers: One 15 mm-thick Megadeco Board both sides.
  • Studs: Single GTEC CS70Rx C studs at 600 mm centres.
  • Insulation: 25 mm-thick, 16 kg/m³ density glass mineral wool (supplied by others).
  • Fire performance (to BS 476-22 and BS EN 1364-1): 60 minutes.

- RMP 062: C Stud Partition:

  • Facing outer layers: One 15 mm-thick Megadeco Board both sides.
  • Studs: Single GTEC CS146Rx C studs at 600 mm centres.
  • Fire performance (to BS 476-22 and BS EN 1364-1): 60 minutes.

- RMP 075: C Stud Partition:

  • Facing outer layers: One 15 mm-thick Megadeco Board both sides.
  • Studs: Single GTEC CS146Rx C studs at 600 mm centres.
  • Insulation: 25 mm-thick, 16 kg/m³ density glass mineral wool (supplied by others).
  • Fire performance (to BS 476-22 and BS EN 1364-1): 60 minutes.

- RMP 127: C Stud Partition:

  • Facing outer layers: One 15 mm-thick Megadeco Board both sides.
  • Studs: Single GTEC CS90Rx C studs at 600 mm centres.
  • Fire performance (to BS 476-22 and BS EN 1364-1): 60 minutes.

- RMP 128: C Stud Partition:

  • Facing outer layers: One 15 mm-thick Megadeco Board both sides.
  • Studs: Single GTEC CS90Rx C studs at 600 mm centres.
  • Insulation: 25 mm-thick, 16 kg/m³ density glass mineral wool (supplied by others).
  • Fire performance (to BS 476-22 and BS EN 1364-1): 60 minutes.

- RMP 130: C Stud Partition:

  • Facing inner layers: One 12.5 mm-thick GTEC dB Board both sides.
  • Facing outer layers: One 12.5 mm-thick Megadeco Board both sides.
  • Studs: Single GTEC CS90Rx C studs at 600 mm centres.
  • Insulation: 25 mm-thick, 16 kg/m³ density glass mineral wool (supplied by others).
  • Fire performance (to BS 476-22 and BS EN 1364-1): 90 minutes.

- RMP 138: C Stud Partition:

  • Facing outer layers: One 15 mm-thick Megadeco Board both sides.
  • Studs: Single GTEC CS90Rx C studs at 600 mm centres.
  • Insulation: 50 mm-thick, 16 kg/m³ density glass mineral wool (supplied by others).
  • Fire performance (to BS 476-22 and BS EN 1364-1): 60 minutes.

- RMP 140: C Stud Partition:

  • Facing inner layers: One 15 mm-thick GTEC dB Board both sides.
  • Facing outer layers: One 15 mm-thick Megadeco Board both sides.
  • Studs: Single GTEC CS90Rx C studs at 600 mm centres.
  • Insulation: 50 mm-thick, 16 kg/m³ density glass mineral wool (supplied by others).
  • Fire performance (to BS 476-22 and BS EN 1364-1): 90 minutes.

System height (maximum):

3.65–8.9 m (dependent on system build-up).
