Rainline Magestic Galvanised Rainwater Downpipe

Rainline Magestic Galvanised Rainwater Downpipe

Lindab Ltd Variant:

Rainline rainwater downpipes and fittings with an unpainted, galvanized surface finish.

Jump to:
+44 (0)1604 788350 www.lindab.co.uk

Application

For use in varying applications, including:

  • Large or small roof areas.
  • Classic or contemporary buildings.
  • Domestic or commercial use.


When selecting gutter and pipe sizes for a rainwater system, the size of the roof and the downpipes (specified separately) position should be considered. This helps ensure that typical rainfall will not cause system overflow. Consult manufacturer for further details.

Description

Rainline rainwater downpipes and fittings with an unpainted, galvanized surface finish.


Features and benefits:

  • Provides an attractive, organic aesthetic.
  • Will weather to a dark grey, metallic appearance within 3–5 years after installation.
  • Low carbon footprint and low overall environmental impact.
  • Durable and flexible.
  • Manufactured from 30% recycled steel, which is lighter than cast iron, easier to handle than aluminium and offers minimal thermal movement compared to plastic.
  • Minimal maintenance required.
  • Highly resistant to attack from vandals.
  • UV stable.
  • Available in four sizes, three lengths, and a range of colour options. Consult manufacturer's literature for details.
  • Quick and easy to install.
  • Supplied with a ten-year warranty.
  • Manufactured in accordance with BS EN 12056-3: 2000.

General information

Color

Unpainted, will weather to a dark grey, metallic appearance within 3–5 years after installation.

-

Finish

Galvanized

With strengthened magnesium zinc alloy.

Material

Steel

Roll formed, 0.6 mm steel with solid seam.

Size

75 x 1000 mm

75 x 2500 mm

75 x 3000 mm

WarrantyDescription

Ten years

Uniclass 2015

Pr_65_52_03_31 Galvanized steel rainwater pipes and fittingsPrimary

CAWS

R10/400 Galvanized steel pipework - threaded

Specification data - Galvanized steel rainwater pipes and fittings Enhanced data

Material

Steel.

Section

Round.

Size (nominal)

75 x 1000 mm.

SROR175MG.

75 x 2500 mm.

SROR2575MG.

75 x 3000 mm.

SROR375MG.

Finish and colour

-

Finish

Galvanized.

Unpainted, galvanized surface finish.

Colour

Self-coloured.

Integral accessories

Selection of brackets, sliding pipes, diverters, hoppers, shoes, connectors, branches, access pipes, offsets and intermediate pipes are available dependent on size.

Product Reference

Rainline Magestic Galvanised Rainwater Downpipe

Type

75 mm downpipe, 1 m length (SROR175MG).

75 mm downpipe, 2.5 m length (SROR2575MG).

75 mm downpipe, 3 m length (SROR375MG).

Bends

BK 70° conical pipe bend, 75 mm (BK7075MG).

BM 70° pipe bend with socket, 75 mm (BM7075MG).

Intermediate pipes

75 mm MST intermediate pipe, 0.5 m (MST0575MG).

75 mm MST intermediate pipe, 1 m (MST175MG).

As drawing.

Contractor's choice.

Offsets

SOKN one-piece offset, 75 mm (SOKN75MG).

As drawing.

Contractor's choice.

Access pipes

75 mm MSTRA rod access pipe, 1 m (MSTRA75MG).

As drawing.

Contractor's choice.

Branches

GROR pipe branch, 75 mm (GROR75MG).

As drawing.

Contractor's choice.

Connectors

SRORM pipe connector, 75 mm (SRORM75MG).

As drawing.

Contractor's choice.

Shoes

BUTK drain shoe, 75 mm (BUTK75MG).

UTK pipe shoe, 75 mm (UTK75MG).

As drawing.

Contractor's choice.

Hoppers

VATKL large water hopper, 75 mm (VATKL75MG).

As drawing.

Contractor's choice.

Diverters

FUTK adjustable diverter, 75 mm (FUTK75MG).

As drawing.

Contractor's choice.

Sliding pipe

PRT sliding pipe, 75 mm (PRT75MG).

As drawing.

Contractor's choice.

Brackets

SHVA downpipe bracket, 75 mm (SVHA75MG).

As drawing.

Contractor's choice.

Hose connector

As drawing.

Contractor's choice.

Pipe holders

SST spike for pipe holder, 125 mm (SST125).

SST spike for pipe holder, 175 mm (SST175).

SST spike for pipe holder, 250 mm (SST250).

SST spike for pipe holder, 300 mm (SST300).

SV pipe holder (for Spike), 75 mm (SV75MG).

Show more

Environmental information

Recycled content

30

Manufactured from 30% recycled steel.
