Opus
Description

Luxury vinyl flooring. Opus is fresh and modern and includes a selection of contemporary greys and concrete effects available in large format planks and tiles.

Features and benefits:

  • The product can be recycled and is phthalate free.
  • Manufactured to EN 649/ EN ISO 10582.
  • CE marked.
  • Indoor Air Comfort certified Gold product to ISO 16000.
  • Classification: 42 light industrial general, 33 commercial heavy and 23 domestic heavy.

Adhesive type:

Suitable for laying with:

  • Karndean Universal.
  • Acrylic.
  • Epoxy.
  • High temperature.
  • Pressure sensitive.

Guarantee:

  • Light industrial and commercial use: 15 years.
  • Residential use: Lifetime guarantee.

General information
Uniclass 2015
Pr_35_57_71_68 Polyvinyl chloride (PVC) tilesPrimary
CAWS

M50/10 Resilient floor tiling

M50/110 Resilient floor tiling

Specification data - Polyvinyl chloride (PVC) tiles
Product Reference

Opus

Type

457.2 x 76.2 mm floor tile

457.2 x 457.2 mm floor tile

609.6 x 457.2 mm floor tile

914.4 x 101.6 mm wood plank

914.4 x 152.4 mm wood plank

1219.2 x 228.6 mm wood plank

Colourway

Various options available; consult manufacturer's literature and insert requirements.

Standard product features

Technical characteristics:

  • Thickness to EN ISO 24346: 2.5 mm.
  • Wear layer to EN ISO 24340: 0.55 mm.
  • Surface treatment: K-Guard+ PU coating.
  • Bevelled edge: Micro.
  • Mass to EN ISO 23997: 4398 g/m².
  • Reaction to fire to EN 13501-1: Bfl-s1.
  • Staining resistance to EN ISO 26987/EN 423: Excellent.
  • Light fastness to EN ISO 105-B02: ≥6.
  • Abrasion resistance to EN 649: Group T. EN ISO 10582: Type 1.
  • Flexibility to EN ISO 24344: Pass.
  • Dimensional stability to EN 434/ EN ISO 23999: Pass.
  • Acoustic impact noise reduction to EN ISO 717-2/ EN ISO 140-8: ΔLw= 2 dB.
  • Electrical behaviour body voltage to EN 1815: Pass.
  • Indentation - residual to EN 433/ EN ISO 24343-1: Pass ≤0.1 mm.
  • Castor chair continuous use to EN 425/ ISO 4918: Pass.
  • Thermal resistance to ISO 8302: 0.0097 m²K/W.
  • Suitable for underfloor heating (maximum 27°C.
  • Slip resistance to DIN 51130: R10 and EN 13893: DS.

Product Options

Type:

Consult manufacturer's technical literature for details, including slip resistance and light reflectance values (LRV).
