Application

Porcelain tile suitable for exterior and interior use in a variety of architectural situations.

Description

Porcelain wall tiles.


Features and benefits:

  • Italian porcelain.
  • Laminated porcelain stoneware.
  • Various sizes available.


Certifications:

  • CE marked.
  • Complies to ISO 13006‐G (Group BIa) and EN 14411‐G (Group Bla) (for outside specifications only).

General information

Color

Black

Finish

Polished

Material

Porcelain

Shape

Rectangle

Length

2600 mm

1200 mm

Width

1200 mm

600 mm

Height

6 mm

Uniclass

Pr_35_93_96_19 Ceramic tilesPrimary

CAWS

Q25/50 Natural stone slabs

Q25/310 Natural stone slabs

Specification data - Ceramic tiles

Standard

To BS EN 14411.

Group

To BS EN 14411, group Bia.

Colour

Maquina Nero.

Finish

Natural.

Honed.

Polished.

Size

1200 x 600 mm.

1200 x 1200 mm.

2600 x 1200 mm.

Thickness

6 mm.

Recycled content

0%.

Dimensions and tolerances

To ISO 10545-2, +/-0.3%; +/-1 mm (max).

Manufacturer guidance

Length and width.

Joint size

1 mm.

Guidance for specification option:

Wall.

Manufacturer guidance

Recommended minimum joint.

Modulus rupture

To ISO 10545-4, 50 N/mm².

Water absorption

To ISO 10545-3, 0.1%.

Abrasion resistance

To ISO 10545-6, ≤175 mm³ (compliant).

DIN 51130

R9.

Fire performance

To EN 13823, Class A1.

ThermalConductivity

To EN 12524, λ 1.3 W/m °K.

Frost protection

To ISO 10545-12, resistant.

Thermal expansion

To ISO 10545-8, α ≤7.10¯⁶ °C¯¹.

Sustainability data

Contains Red List materials

No

Country of material origin

Italy

Country of product manufacture

Italy

Recycled content

As defined in clause 7.8 of BS EN ISO 14021

40 %
