This product is no longer available

Application

  • Closed cell timber frames.
  • Open cell timber frames.
  • Fire rated modular construction.
  • Loaded fire walls.
  • Prisons.
  • Park homes.
  • Anti-vandal units.
  • Wood burning stove surrounds.

Description

A medium density magnesium oxide building board which has been developed to provide the System Build and Off-site Construction markets with a new fire rated loaded external wall panel system. It is A1 non-combustible and provides a stable substrate to which various finishes can be bonded.

Externally, it can be faced with plastisol steel, acrylic based render systems, or brick slips. Internally, fire rated laminated plasterboard using Cova PVC coverings can be used to provide the desired finish.

Applications:

  • Closed cell timber frames.
  • Open cell timber frames.
  • Fire rated modular construction.
  • Loaded fire walls.
  • Prisons.
  • Park homes.
  • Anti-vandal units.
  • Wood burning stove surrounds.

Approvals:

  • Chiltern, Exova Warrington fire, PSB, Lucideon, BPAC, Milner Associates (Racking) certified.
  • BBA Approved.
  • BRE Non-Combustibility Test.

General information
Size

2400 x 1200 mm

2440 x 1200 mm

6.5 mm thickness only.

2700 x 1200 mm

6.5 mm and 9 mm thickness only.

3050 x 1200 mm

Color

White

Features

Impact resistant, low carbon manufacturing process, moisture and water resistant, rodent resistant, mould resistant, chemically stable

Material

Inorganic substances, Si02, CaCO3, MgO, MgCl2 and alkaline resistant fibreglass mesh

Shape

Rectangular

Uniclass 2015
Pr_25_71_52_50 Magnesium oxide boardsPrimary
Specification data - Magnesium oxide boards
Product Reference

Multi-pro XS

Size

2400 x 1200 mm

2440 x 1200 mm

6.5 mm thickness only.

2700 x 1200 mm

6.5 mm and 9 mm thickness only.

3050 x 1200 mm

Thickness

6.5 mm

9 mm

12 mm

Standard product features

Colour:

White.

Density:

1050 kg/m³.

Fire rating:

A1 Non-Combustible

Impact strength:

34 N/mm².

Mould resistance:

2A to BS EN 60068-2-10.

Edges:

Square.

Product Options

Size/ Thickness:

Other sizes available on request depending on quantity, consult manufacturer.

Digital objects
PlatformCompatibleVersionCertified to
IFC
IFC2X3 3 1.3
Revit
Revit 2016 4 2.0
Download now from NBS National BIM Library
