Interior use high-pressure laminate panel.
For heavy-duty areas of application (e.g., office furniture, protective wall cladding, wet rooms, etc.) with increased demands for fire resistance. Max Compact F Quality is not only suitable for use in sanitary and wet rooms. The quality of the panels means that it is also suitable for all other indoor usages such as wall cladding, railing infill panels, furniture, tables, desks, column cladding and lab equipment etc.
FunderMax Compact Interior panels are high-pressure laminate panels (HPL) manufactured to standard EN 438 that are produced in laminate presses under high pressure at high temperature. They are particularly suitable for demanding and decorative applications (e.g. furniture, office furniture, wall cladding, sanitary facilities etc).
As a standard, Max Compact panels come with decors on both sides. The core is black and the surfaces are available in different structures.
FunderMax offers CNC controlled processing and panel cutting. With state-of-the-art devices, it is possible to produce everything from simple cut-outs for mounting the facade panels, to intricate milling for balcony elements. Consult manufacturer for details and specify requirements under 'Special' below.
Features and benefits:
Application:
For heavy-duty areas of application (e.g., office furniture, protective wall cladding, wet rooms, etc.) with increased demands for fire resistance. Max Compact F Quality is not only suitable for use in sanitary and wet rooms. The quality of the panels means that it is also suitable for all other indoor usages such as wall cladding, railing infill panels, furniture, tables, desks, column cladding and lab equipment etc.
Finish | Double sided: Fine hammer embossed or matt to both sides Single sided: Fine hammer embossed or matt (top side), Melamine sanded (reverse side) |
Features | Scratch resistant, easy to clean, solvent resistant, heat resistant, food grade, quick installation, impact resistant and durable. FSC and PEFC certified |
Material | High-pressure laminate panels (HPL) according to EN 438-4 |
Shape | Rectangular |
Size | 2140 x 1060 mm (2–20 mm), 2800 x 1300 mm (2–20 mm), 2800 x 1854 mm (2-15 mm), 4100 x 1300 mm (2–20 mm), 4100 x 1854 mm (2–20 mm) |
Uniclass 2015 | |
CAWS | K13/140 Proprietary laminated plastics-veneered panel lining K13/145 Proprietary plastics cladding Q40/30 Proprietary fencing Q40/430 Proprietary fencing |
Product Reference | Max Compact Interior F-Quality Double SidedStandard. Max Compact Interior F-Quality Single Sided |
Grade | As per EN 438-4, Type CGS |
FireRating | Classification according to EN 13501-1: Euroclass B - s2, d0 for 4-20 mm, Euroclass B - s1, d0 for 6-20 mm if mounted with a maximum gap of 15 mm B1 “schwer entflammbar” according to DIN 4102-1 |
Thickness | 2–20 mm except 2800 x 1854 mm only 2–15 mm. (2–4 mm single sided). |
Panel size | - |
Length | 2140 mm2800 mm4100 mm |
Width | 1060 mm1300 mm1854 mm |
Edges | Non-bevelled cut edges as standard; edge processing is possible |
Colour | Wide range of decors, see manufacturer's literature for details. |
Specials | Not requiredFine hammer embossed or matt (surface) |
Fixing | A variety of options for fixing exist, including mechanical fastening, consult the manufacturer for details and insert requirements. |
Apparent density | DIN 52350/ EN ISO 1183 ≥1.35 g/cm³ |
Flexural strength to EN ISO 178 | ≥80 MPa |
E-Modulus to EN ISO 178 | ≥9000 MPa |
Coefficient of thermal expansion to EN 61340-4-1 | 20 x 10^-6 1/K |
ThermalConductivity | 0.3 W/mK |
Water vapour diffusion resistance | 17.200 μ |
Resistance against stress abrasion to EN 438-2 | ≥150 U |
Resistance against scratching to EN 438-2 | ≥3 Degree (4 N) |
Susceptibility to cracking to EN 438-2 | ≥4 |
Light fastness to EN 438-2 | ≥4 |
Standard product features | Colour: Black (core), surfaces are available in different decors. Features: Scratch resistant, easy to clean, solvent resistant, heat resistant, food grade, quick installation, impact resistant and durable. FSC and PEFC certified. Finish:
Material: High-pressure laminate panels (HPL) according to EN 438-4. Shape: Rectangular. Size: 2140 x 1060 mm (2–20 mm), 2800 x 1300 mm (2–20 mm), 2800 x 1854 mm (2-15 mm), 4100 x 1300 mm (2–20 mm), 4100 x 1854 mm (2–20 mm). Recyclability: Made from 65% natural fibre panels. Production waste is used to generate energy in Fundermax's green energy district heating plants. Red Listed materials: The panels do not contain organic halogens (or chlorine, fluorine, bromine, etc.) compounds such as are found in greenhouse gases or PVC. They contain neither asbestos nor wood protection agents (fungicides, pesticides,etc.) and are free of sulfur, mercury and cadmium. Country of Origin: Austria. |
Recyclability | Made from 65% natural fibre panels. Production waste is used to generate energy in Fundermax's green energy district heating plants |
