Hawa Multifold 30 W

Application

Suitable for use in interior design and furniture projects, for use in areas such as hotels.

Acts as a supplementary product to the Hawa Multifold 30 - consult manufacturer for details.

Description

Furniture hardware for walk-in cabinet doors with a maximum panel weight of 30 kg (or 60 kg for a pair). Maximum height: 2600 mm. Door width: 200–500 mm. Suitable for door panel thickness of 19–25 mm.

Features and benefits:

  • For attachment to one side with concealed hinges.
  • Can be used for sliding a door both to the left and right.
  • Can incorporate inlaying or full overlaying cabinet doors.
  • Does not require a floor guide.
  • Simple, smooth operation.
  • Vertical adjustment (±2 mm).

Components:

  • Trolley with two plastic tyred wheels and two guide rollers.
  • Suspension unit.
  • Set of countersunk head press screws, 4 x 16 mm.
  • Set of fixing screws.
  • Centre hinge, with fixing screws.
  • Door catch, plastic (black), with fixing screws.
  • Retaining bumper on top.
  • Panel surface equaliser, plastic (black).
  • Surface equaliser for side wall.
  • Top track, 1100 mm, aluminium plain anodized, predrilled, with brush seal (standard, 15569 only).

Applications:

Suitable for use in interior design and furniture projects, for use in areas such as hotels.

Acts as a supplementary product to the Hawa Multifold 30 - consult manufacturer for details.

General information

Uniclass 2015

Pr_30_36_36_23 Door track and running gearPrimary

CAWS

N10/10 Purpose-made

N10/110 Purpose-made

P21/10 Quantities and locations

P21/350 Door track and running gear

Specification data - Door track and running gear

Product Reference

Hawa Multifold 30 W (15569)

Set for walk-in cabinet with top track. For two panels.

Hawa Multifold 30 W (18286)

Set for walk-in cabinet without top track For two panels.

Installation/ Design

Insert requirements, various possibilities available including inlay/ semi overlay and full overlay. Consult manufacturer for details.

Top track

Not required

For 18286.

1100 mm

Standard.

1800 mm

2500 mm

6000 mm

Vertical seal profile

Not required

Black (RAL 9011)

5 m roll.

White (RAL 9010)

5 m roll.

Locking

Not required

Furniture bar bolt lock with Kaba-8-cylinder (separate locking)

Furniture bar bolt lock with one euro key (simultaneous locking)

Accessories/ Other requirements

Not required

Concealed hinge, dull nickel finish, 110° (inset panels)

Concealed hinge, dull nickel finish, 120° (overlaying panels)

Mortising template for cup recesses

Standard product features

Configuration:

Sliding/ folding.

Product Options

Top track:

Aluminium plain anodized, pre-drilled, with brush seal.

Locking:

27/ 110/ 8 mm, nickel finish. Consult manufacturer for further details.

Accessories/ Other requirements:

Other accessories and spares are also available, consult manufacturer for details.
