Sliding hardware with two-way suspension, for use with single wooden doors with a panel weight up to 40 kg.
Sliding hardware with two-way suspension, for use with single wooden doors with a panel weight up to 40 kg.
Features and benefits:
Components:
Quantities of each component will vary dependent on variant specified - consult manufacturer for details.
For two-panel sliding doors, order two sets for single doors. Consult manufacturer for further details.
Uniclass 2015 | |
CAWS | P21/10 Quantities and locations P21/350 Door track and running gear |
Product Reference | HAWA Junior 40 Z (25902)HAWA Junior 40 Z, with two track stops (26038)Required if the sliding door needs to stop at both ends. |
Configuration | Top hungStandard. Wall pocketSee 'Options' for details. |
Running track | 1400 mm1600 mm1800 mm2000 mm2500 mm3000 mm4000 mm6000 mmCut to sizeInsert requirements. |
Closing mechanism | Not requiredSoftMove 40 |
Accessories/ Other requirements | Not requiredBottom door stopAvailable with dull chromium or stainless steel finish; insert requirement. Cover cap for running trackPlastic, anthracite grey (RAL 7016). Guide profileBlack, plastic. Groove mounted. 1300 mm length. Set for mountable and demountable running trackSpring-loaded door stop |
Product Options | Configuration: - Wall pocket: Supplied with alternative guide, 35 mm long and laterally adjustable. Enables the door to be pushed into a finished wall pocket. Combined with assembly set for HAWA Junior 40. Consult manufacturer for details. Running track: Aluminium, plain anodized, pre-drilled (hole positions vary - consult manufacturer for details). Accessories/ Other requirements: Spares are also available, consult manufacturer for details. |
