Folding Bike Lockers

Verified by manufacturer 4 days ago

Laminate (dry)

Helmsman Variant:

A folding bike storage solution.

Jump to:
BOS
+44 (0)1284 530427 Website

Application

Suitable as a place to store bicycles safely.

Description

A folding bike storage solution.

As standard, lockers are fitted with a camlock or hasp lock, or contact manufacturer for alternatives.

Helmsman Folding Bike Lockers are available with the option of a perforated body and/or door.

Helmsman offer four options when it comes to materials and finish for folding cycle lockers (laminate wet, laminate dry, metal wet, metal dry).


Features and benefits:

  • Bespoke options available.
  • Standard size of 1250 mm high x 340 mm wide x 700 mm deep for one compartment, with the option of one to three compartments available.
  • Two-compartment locker is size 1600 mm high x 340 mm wide x 700 mm deep.
  • Manufactured in the UK to a high standard.
  • Door and body can be perforated as an additional option.


Laminate:

  • Dry specification lockers made with mild steel body and solid grade laminate door.
  • Wet specification lockers made with stainless steel frame, aluminium body and solid grade laminate door.
  • Various laminate colours available.


Metal:

  • Dry specification lockers made from mild steel.
  • Wet specification lockers made with stainless steel frame, aluminium body and zinc plated door.
  • Standard RAL metal colours are available.

General information

Color

Black

Guidance for specification option:

  • RAL 9005.
  • Jet.

Blue

Guidance for specification option:

  • Royale (RAL 5002).
  • Skye (BS 18 E 51).
  • Cobalt.
  • Atoll.

Green

Guidance for specification option:

  • Forest green (BS 14 C 39).
  • Lime.

Grey

Guidance for specification option:

  • Classic Grey.
  • Smoke (RAL 7031).
  • Graphite.

Orange

Guidance for specification option:

Pumpkin (RAL 2010).

Show more

Finish

Laminated

Powder-coated

Material

Laminate

Steel

Stainless steel

Aluminium

Shape

Rectangle

Length

650 mm

Manufacturer guidance

Depth.

Width

400 mm

Height

2100 mm

Warranty description

One year

Uniclass

Pr_40_30_87_48 LockersPrimary

CAWS

N10/10 Purpose-made

N10/220 Lockers

Q50/212 Cycle lockers

Specification data - Lockers

Locker type

Laminate dry.

Guidance for specification option:

For a dry area, laminate folding bike lockers come manufactured with a mild steel body and a solid grade laminate door. This laminate comes in a range of colours and finishes.

Dimensions

1250 x 340 x 700 mm.

Guidance for specification option:

Standard.

1600 x 340 x 700 mm.

Guidance for specification option:

Two compartment locker.

Manufacturer guidance

Height x width x depth.

Material

Mild steel body, solid grade laminate door.

Finish

Laminate.

Colour

Egyptian White.

Classic Grey.

Jet.

Graphite.

Cobalt.

Crimson.

Tropical.

Lime.

Atoll.

English Oak.

Fittings

Camlock.

Hasp lock.

Other.

Guidance for specification option:

Contact manufacturer for alternative locking systems and insert requirements.

NumberOfCompartments

One.

Two.

Three.

Perforations

Not required.

Door.

Body.

Sustainability data

Contains Red List materials

No

Country of material origin

United Kingdom

Country of product manufacture

United Kingdom

Material

Laminate

Steel

Stainless steel

Aluminium

Recyclability

Mild Steel, Aluminium

BIM objects

BOS

NBS BIM Object Standard

This BIM object has been authored to meet the requirements of the NBS BIM Object Standard.

Find out more about the NBS BIM Object Standard.

Platform Compatible Version
Revit
-

1

IFC
-

1

Literature

Laminate Folding Bike Lockers

Laminate Folding Bike Lockers

Metal Folding Bike Lockers

Metal Folding Bike Lockers
