Description

Door leaves are constructed from 64 mm high performance timber based composite core encapsulated by high quality hardwood stiles and rails faced with MDF, plywood or chipboard which will then be covered with decorative wood veneers, plastic laminates, stains or paint as required. Can be partnered with Fields Wall Panelling for a fully coordinated design.

Features:

  • Available fire ratings: FD30 or non-fire rated.
  • Acoustic performance up to 44 dB.
  • Cold smoke protection can be accommodated.
  • Available as fully FSC certified doorset.

General information
Size

Insert requirements.

Finish

Clear lacquer

Factory painted

Final finish

Can be matt or high gloss as required.

Primed for onsite painting

Stain

Tinted lacquer

Features

Available fire ratings: FD30 or non-fire rated

Acoustic performance up to 44 dB

Cold smoke protection can be accommodated

Available as fully FSC certified doorset

Uniclass 2015
Wood doorsets (Pr_30_59_24_97)Primary
Specification data - Wood doorsets
Product Reference

Fields Acoustic Hybrid Doorset FD30

Fields Acoustic Hybrid Doorset non-fire rated

Size

Insert requirements.

Glazing -
Type

Insert requirements.

Size

Insert requirements.

Shape

Insert requirements.

Facing

Hygienilac PVC

Antibacterial facing.

Laminate

Exposed lippings.

PVC

Exposed lippings.

Wood veneer

Book, slip or random matched and laid either vertically or horizontally.

Finish

Clear lacquer

Factory painted

Final finish

Can be matt or high gloss as required.

Primed for onsite painting

Stain

Tinted lacquer

Ironmongery

Insert requirements.

Standard product features

Size (maximum):

  • Height: 2500 x 3225 mm.
  • Width: 2500 x 3225 mm.

Thickness:

64 mm.

Product Options

Performance:

Fire resistance test to BS 476-22 by Chiltern International Fire Ltd.

Glazing:

Factory glazed using clear laminated fire/ acoustic resisting glass in conjunction with necessary seals. The glass is retained using a purpose made, pinned hardwood splayed and rebated cloak type glazing beads. For fire rated leaves the maximum permitted glazed area per leaf must not exceed 0.36 m² throughout the configuration range. Aperture shape is unrestricted and may be in multiple or single paned form providing glazing is not less than 100 mm from any door edge and not less than 80 mm between apertures.

Frame and architraves:

Supplied with a 640 kg/m³ density or greater hardwood of minimum section 90 x 32 mm after rebating or profiling.

Over panels:

One piece over panels not greater than the width of door leaf/ leaves are permitted in all configurations with a separating transom. A rebated or square interface between door leaf and over panel is also permitted without transom. Maximum allowed heights are:

  • Single leaves: 2000 mm.
  • Double leaves: 1500 mm.

Lipping:

All doors will be supplied with hardwood exposed square lippings to vertical edges.

Ironmongery:

An extensive range of ironmongery is permitted for use.
