Continuously Slotted Acoustic Ceiling

Application

For use as ceiling linings.

Description

Continuously slotted absorption ceiling panels providing a versatile solution for the control of reverberation where true flexibility, aesthetic appeal and acoustic performance is required. It is available in planked and complete panels. This product enables the creation of a seamless appearance with clean lines to greatly improve the ambiance of any room.

The panels have continuous slots (grooves) to the face and reverse, with the boards being drilled from edge to edge through the core to create acoustic cavities which absorb sound.

Applications:

For use as ceiling linings.

General information

Size

3600 x 192 mm

Special order

Insert requirement.

Material

Medium density fibreboard (MDF) core with a black acoustically transparent tissue backing

Uniclass 2015

Pr_35_93_13_80 Sound attenuator infill unitsPrimary

CAWS

K40/10 Unit/ modular suspended ceilings

K40/105 Suspended ceiling system

K40/115 Unit/ modular suspended ceiling system

K40/270 Boards

Product range

Acoustic Panels

Specification data - Sound attenuator infill units

Product Reference

Continuously Slotted Acoustic Ceiling

Size

3600 x 192 mm

Special order

Insert requirement.

Face finish

Insert requirement, available in melamine, painted or veneer finishes, consult manufacturer's literature for information.

Slots

9/3

14/2

13/3

28/4

Special order

Insert slot width and spacing requirement.

Core fire rating

Euro Class D

Fire rated

Standard product features

Material:

Medium density fibreboard (MDF) core with a black acoustically transparent tissue backing.

Thickness:

16 mm.

Edges:

  • Long edges: One edge tongue and one edge grooved.
  • Ends: Straight.

Sound absorber class (to BS EN ISO 11654):

Class D, C, B or A (dependent on insulation and depth of cavity behind panels).

Sound absorption coefficient (to BS EN ISO 11654):

Dependent on air gap, insulation and depth of cavity behind panels.

Fire performance:

B-s3, d0 - Euro Class B
