Colinwell Common Blocks
Application

Suitable for the construction of all types of walls including those below ground and foundations. They can also be used for T-Beam block floor systems.

Description

Colinwell dense aggregate common concrete blocks are durable, robust and have excellent loadbearing, fire resistance and sound insulation qualities. Manufactured to BS EN 771-3.

Features and benefits:

  • Established, proven and familiar building product - a totally risk-free wall construction method.
  • Versatile, durable and strong.
  • Ideal background for drylining, plaster, render and fixings.
  • Excellent sound insulation qualities.
  • Inherent thermal mass acts as heat store.
  • Cost effective.
  • Fire resistant.
  • Readily available.
  • Recyclable.

Application:

Suitable for the construction of all types of walls including those below ground and foundations. They can also be used for T-Beam block floor systems.

General information

Material

Concrete manufactured in accordance with BS EN 771-3: 2011

Uniclass 2015

Pr_20_93_52_01 Aggregate concrete blocksPrimary

CAWS

F10/355 Concrete common blockwork

F10/36 Concrete common blockwork

Specification data - Aggregate concrete blocks

Product Reference

Colinwell Common Blocks

Type

Insert requirement from 'Options' below.

Density

Insert requirement or type 'Manufacturer's standard'.

Standard product features

Colour:

Natural.

Material:

Concrete manufactured in accordance with BS EN 771-3: 2011.

Technical characteristics:

Dependent on block type, consult manufacturer's literature for information.

Product Options

Type:

  • A1 - Solid unit, 440 x 100 x 215 mm (l x w x h).
  • A3 - Hollow/ cellular unit, 440 x 190 x 215 mm (l x w x h).
  • A3 - Hollow/ cellular unit, 440 x 215 x 215 mm (l x w x h).
  • A4 - Half unit, 215 x 190 x 215 mm (l x w x h).
  • A4 - Half unit, 215 x 215 x 215 mm (l x w x h).
  • A6 - Hollow/ cellular unit, 440 x 140 x 215 mm (l x w x h).
  • A7 - Half unit, 215 x 100 x 215 mm (l x w x h).
  • A8 - Hollow/ cellular unit, 440 x 140 x 215 mm (l x w x h).
  • A9 - Solid unit, 440 x 75 x 215 mm (l x w x h).
  • A11 - Solid unit, 440 x 100 x 140 mm (l x w x h).
  • A12 - Solid unit, 440 x 100 x 100 mm (l x w x h).
  • A13 - Solid unit, foundation block, 330 x 300 x 100 mm (l x w x h).
  • B2 - Closer unit, 390 x 90 x 190 mm (l x w x h), cut to suit cavity width.
  • B4 - Closer unit, 190 x 90 x 190 mm (l x w x h), cut to suit cavity width.
  • B6 - Bond beam, 390 x 190 x 190 mm (l x w x h).
  • B8 - Bond beam, 440 x 215 x 215 mm (l x w x h).
  • C1 - Solid unit, 390 x 90 x 190 mm (l x w x h).
  • C3 - Solid unit, 390 x 140 x 190 mm (l x w x h).
  • C4 - Hollow unit, 390 x 190 x 190 mm (l x w x h).
  • C7 - Hollow unit, 390 x 140 x 190 mm (l x w x h).
  • D2 - Closer unit, 440 x 100 x 215 mm (l x w x h), cut to suit cavity width.
  • D4 - Closer unit, 215 x 100 x 215 mm (l x w x h), cut to suit cavity width.
  • SQ1 - Squint unit 45°, 300 x 90 x 190 mm (l x w x h).
  • SQ5 - Squint unit 30°, 330 x 100 x 215 mm (l x w x h).
  • SQ5 - Squint unit 45°, 330 x 100 x 215 mm (l x w x h).
  • SQ5 - Squint unit 60°, 330 x 100 x 215 mm (l x w x h).
  • SQ8 - Squint unit 45°, 345 x 140 x 215 mm (l x w x h).
