This product is no longer available

Description

The ASSA ABLOY SW200 I integrated swing door system is designed for entrances where aesthetics, superior safety and sustainability are important. With no visible arm and an integrated operator, this door system is unique on the market and makes a perfect fit to entrances in harsh environments like schools and transport hubs. With no visible operator, this door system doesn’t require any extra cleaning on top of the operator and arm.

General information
Specification data - Controlled door closers
Product Reference

Automatic Swing Door Opener - ASSA ABLOY SW200 I

Opener

SW200 I-1

SW200 I-2

Arm system

Inward opening

Outward opening

Accessories

None

Intelligent door selector

Ensures that pairs of rebated doors close in the correct sequence.

Integrated finger trap protection device

Impulse detection sensors

Presence detection sensors

Safety Barriers

Standard product features

Operator:

- ASSA ABLOY SW200 I-1:

For single doors, comprising one drive unit, frame, door leaf and one control unit fitted under a standard length cover.

- ASSA ABLOY SW200 I-2:

For double doors, comprising two drive units, frame, two door leaves with control units fitted under a cover.

Glazing:

  • 6 mm/ 8 mm/ 10 mm, single glazed.
  • 22 mm/ 40 mm insulated.

Locking:

  • Electric.
  • 1 x mechanical lock.
  • 2 x mechanical lock.

Cover:

Clear anodized aluminium, alternative paint colours are available on request.

Power supply:

  • 230 V AC, 50 Hz.
  • 120 V AC, 60 Hz.

Auxiliary voltage:

  • 13–20 V DC.
  • 24 V DC.

Product Options
