Alu Rapid Staging Platform

Third party certifications:

QA Certificate
Certificate type

Standard platform with removable stick feet.

Jump to:

+44 (0)1302 238124 www.cpsmanufacturingco.com/?utm_source=nbs

Size

1000 x 1000 mm

Weight: 22 kg.

2000 x 1000 mm

Weight: 35 kg.

Material

Aluminium and timber

Uniclass 2015

Pr_40_30_25_21 Demountable podiums and stagingPrimary

CAWS

N10/178 Demountable podia and staging

Product Reference

Alu Rapid

Alu Rapid V, round legs

Consult manufacturer and insert leg size.

Alu Rapid V, square legs

Consult manufacturer and insert leg size: 60 x 60 mm (maximum).

Size

1000 x 1000 mm

Weight: 22 kg.

2000 x 1000 mm

Weight: 35 kg.

Floor surface

22 mm hardwood veneered blockboard, black stained

22 mm hardwood veneered blockboard, brown stained

22 mm hardwood veneered blockboard, clear lacquered

Carpet

Various colours available, insert requirements.

Galvanized steel mesh

Hardwood

Karndean floor

Perspex

Vinyl

Waterproof anti-slip floor

Valance

Not required

Carpet

Curtain

Branding or logos also available, insert requirements.

Hardwood

Hardwood corner post

Laminate boarding

Branding or logos also available, insert requirements.

PVC curtain

Stained plywood

Frame height

80 mm

200 mm

400 mm

600 mm

800 mm

1000 mm

3000 mm

Accessories

Not required

Box section steps

Chair holding border

Compact curtain

Fascias

Heavy duty handrail

Standard handrail

Standard infilled handrail

Step balustrade standard

Storage wheels

System steps

Timber balustrade

Timber steps

Valance curtain

Standard product features

Material:

Aluminium and timber.

Storage:

Up to 20 high on top of each other on transport wheels i.e. 40m² of staging stored in 2 m² of floor area.

- Storage height:

80 mm.

Operation:

Aluminium legs are placed in the corner sockets and wing nuts tightened by hand. The leg is securely held in the corner by means of a sliding 'T' piece.

Design load:

765 kg/m² evenly distributed.

Product Options

Size:

Standard sizes of 1000 x 1000 mm or 2000 x 1000 mm available, however virtually any size available using bespoke service.

Leg size:

40 x 40mm.

60 x 60 mm.

Frame height:

Standard sizes 200, 400, 600, 800 or 1000 mm.

Any height from 80–3000 mm available using bespoke service.

Accessories:

An extensive range of accessories are available, consult manufacturer for details and insert requirements.

Size	1000 x 1000 mm Weight: 22 kg. 2000 x 1000 mm Weight: 35 kg.
Material	Aluminium and timber
Uniclass 2015	Pr_40_30_25_21 Demountable podiums and stagingPrimary
CAWS	N10/178 Demountable podia and staging

Product Reference	Alu Rapid Alu Rapid V, round legs Consult manufacturer and insert leg size. Alu Rapid V, square legs Consult manufacturer and insert leg size: 60 x 60 mm (maximum).
Size	1000 x 1000 mm Weight: 22 kg. 2000 x 1000 mm Weight: 35 kg.
Floor surface	22 mm hardwood veneered blockboard, black stained 22 mm hardwood veneered blockboard, brown stained 22 mm hardwood veneered blockboard, clear lacquered Carpet Various colours available, insert requirements. Galvanized steel mesh Hardwood Karndean floor Perspex Vinyl Waterproof anti-slip floor
Valance	Not required Carpet Curtain Branding or logos also available, insert requirements. Hardwood Hardwood corner post Laminate boarding Branding or logos also available, insert requirements. PVC curtain Stained plywood
Frame height	80 mm 200 mm 400 mm 600 mm 800 mm 1000 mm 3000 mm
Accessories	Not required Box section steps Chair holding border Compact curtain Fascias Heavy duty handrail Standard handrail Standard infilled handrail Step balustrade standard Storage wheels System steps Timber balustrade Timber steps Valance curtain
