22 mm two strip parquet clip system floating floors
Description

Solid hardwood flooring system featuring 129 x 3700 mm (w x l) boards manufactured from two rows of graded hardwood staves, dovetail jointed together. A moisture balancer is applied to the underside. The boards have precision machined tongued and grooved edges, which facilitate assembly and ensure square, secure joints. Designed for heavy wear and durability. Suitable for installation over underfloor heating (consult Junckers for special details), but should not be used in wet areas. Available in a range of factory finishes which, if necessary, can be refinished using suitable cleaning agents, oils and lacquers. Renovation by in-situ precision sanding and refinishing is also possible. FSC and PEFC accredited.

General information

Material

Hardwood

WarrantyDescription

Labor: 25 year project specific where fitted by an approved contractor, Parts: 10 year project specific or 25 year where fitted by approved installer

Uniclass 2015

Ss_30_20_95_95 Wood floating floor systemsPrimary

CAWS

K21/111 Wood floating floor

Specification data - Wood floating floor systems

Product Reference

22 mm Two Strip Clip System Floating Floors

Species

Ash

Beech

Black Oak

Driftwood Grey

Midnight Black

Nordic Ash

Nordic Beech

Nordic Oak

Nordic Sylvaket

Oak

Oak Golden Pearl

Oak Natural Pearl

Oak Silver Pearl

Sylvacolor

SylvaKet

Sylvared

Appearance

Classic

Harmony

Variation

Finish, as delivered

Untreated

Urethane rustic oil

UV light cured lacquer plus Junckers polyurethane Isolacquer – Silk Matt

UV light cured lacquer plus Junckers polyurethane Isolacquer – Ultra Matt

Underlay

2 mm Polyfoam underlay (including moisture barrier)

2 mm Sylvafoam underlay

5 mm Multifoam underlay

10 mm Profoam underlay

Vapour control layer

Not required

Junckers SylvaThene

Accessories

None

Expansion strip

Nosing

Skirting

Stair nosing

Standard product features

Method of fixing/ joining:

Junckers clip system.

Finished face width:

129 mm.

Length:

3700 mm length for 22 mm thick boards.

Product Options

Fixing method:

Junckers proprietary clip system:

  • Residential floors: 13 clips/m².
  • Non-residential floors: 17 clips/m².

Clip size:

Clip size is determined by the expected range of relative humidity in the building through the year. Contact Junckers for specific recommendations. Clip sizes:

  • 129.1 mm.
  • 129.4 mm.
  • 129.8 mm.

Digital objects
PlatformCompatibleVersionCertified to
IFC
IFC2X3 1 1.3
Revit
Revit 2016 3 2.0
Download now from NBS National BIM Library
