V77 Elite SR2 Aluminium Security Shutter

Name: V77 Elite SR2 Aluminium Security Shutter
Brand: Roché Systems Ltd
SKU: iQCBiLRnxUDXdQGNgZLvPD

Verifisert av produsent for 1 måned siden

Roché Systems Ltd

Produktsertifiseringer:

LPCB Certification
Sertifikattype

LPCB SR2 insurance approved extruded aluminium security roller shutters with 77 mm high slats.

Gå til:

BOS

03330347967 Nettside

Applikasjon

Suitable for commercial sites and shopfronts that require high security.

Beskrivelse

Extruded aluminium security roller shutters with 77 mm high slats and designed to suit specific site requirements.

Features and benefits:

Tested by the Loss Prevention Certification Board (LPCB) to LPS 1175 SR2 and awarded insurance approved 'Secured by Design' status. Mounted internally, externally or reveal fixed.
Span up to 5 m in width and an area up to 25 m².
Available with solid and punched profiles.

Generell informasjon

Farge	White Brown Other Veiledning for spesifikasjonsvalg: Option to powder coat any RAL/ BS colour or laminate wood effect (surcharge applies).
Overflatebehandling	Galvanized Laminated Veiledning for spesifikasjonsvalg: Plastisol coated - wood effect. Powder-coated Produsentveiledning Option to powder coat any RAL / BS colour or laminate wood effect (surcharge applies).
Materiale	Aluminium
Form	Rectangle
Lengde	Bespoke
Bredde	Bespoke
Høyde	Bespoke
Garantibeskrivelse	One year

Uniclass	Pr_30_59_84_73 RulleporterPrimær
CAWS	L20/60 Doors L20/610 Roller shutters/ curtains

Product range	Vision Roller Shutters

Spesifikasjonsdata - Rulleporter

Klassifiseringsdata
Opening sizes	5000 x 4000 mm. Veiledning for spesifikasjonsvalg: Available up to 5000 x 4600 mm (w x h). Veiledning fra produsent Enclosure size (internal face fix): Dependent on height. <2700 mm: 300 mm. 2700–3640 mm: 360 mm. 3640–4600 mm: 400 mm.
Arrangement	Vertical, external face fix. Vertical, internal face fix. Vertical, reveal fix.
Shutter curtain.	-
Lath material	Aluminium. Veiledning for spesifikasjonsvalg: 18.5 mm thick solid single skinned extruded aluminium, 77 mm in height.
Finish and colour	Galvanized. Veiledning for spesifikasjonsvalg: Standard finish. Powder coated - Brown. Veiledning for spesifikasjonsvalg: Standard colour. Powder coated - White. Veiledning for spesifikasjonsvalg: Standard colour. Powder coated - BS. Veiledning for spesifikasjonsvalg: Insert colour requirement. Powder coated - RAL. Veiledning for spesifikasjonsvalg: Insert colour requirement. Laminated wood effect. Veiledning fra produsent Option to powder coat any RAL / BS colour or laminate wood effect (surcharge applies).
Frame and guides	-
Material	Aluminium. Veiledning for spesifikasjonsvalg: Enclosure: Roll formed aluminium box with pressure-moulded aluminium alloy end caps. Guide channels: 150 mm deep heavy duty extruded aluminium. To comply with LPCB certification, the channels must be installed 30 mm from the opening, allowing 180 mm from the opening edge to the back of the guide channels. Bottom slat: Extruded aluminium with brush and rubber weather seals.
Finish	Galvanized. Veiledning for spesifikasjonsvalg: Standard finish. Powder coated. Veiledning for spesifikasjonsvalg: See below for colour requirements.
Colour	Not required. Veiledning for spesifikasjonsvalg: Galvanized. Brown. Veiledning for spesifikasjonsvalg: Standard colour. White. Veiledning for spesifikasjonsvalg: Standard colour. Powder coated - BS. Veiledning for spesifikasjonsvalg: Insert BS colour code. Powder coated - RAL. Veiledning for spesifikasjonsvalg: Insert RAL colour code.
Operation	-
Mode	Automatic. Veiledning for spesifikasjonsvalg: Somfy Electric Single Phase (Tubular Motor) with safety brake.
Control	Somfy tubular motor and internal rocker or external key switch as standard. NRG tubular motor and internal rocker or external key switch as standard.
Accessories	Not required. Manual override facility. Polycarbonate infills.
Guide channel depth	150 mm. Veiledning for spesifikasjonsvalg: Guide channels must be fitted 30 mm from the opening, giving180 mm from opening edge to back of guide.
Vekt	5.5 k.g./m².
Enclosure	Box. Circular.
