P76 Perforated Steel Security Shutter

Name: P76 Perforated Steel Security Shutter
Brand: Roché Systems Ltd
SKU: m23RD6eepmK8MJ6AabAW9X

Verifisert av produsent for 1 måned siden

Steel

Roché Systems Ltd

Single skin curved steel roller shutters with 76 mm high slats.

Gå til:

BOS

03330347967 Nettside

Applikasjon

Windows, doors and openings in commercial and industrial uses.

Beskrivelse

Single skin curved steel roller shutters with 76 mm high slats, available with solid, punched and perforated profiles. Punched and perforated slats can be incorporated as required for full or partial vision. The shutter can span up to 12m in width and an area up to 50 m².

Generell informasjon

Overflatebehandling	Galvanized Powder-coated Plastisol
Materiale	Steel Aluminium
Lengde	Bespoke
Bredde	Bespoke
Høyde	Bespoke
Garantibeskrivelse	One year

Uniclass	Pr_30_59_84_73 RulleporterPrimær
CAWS	L20/60 Doors L20/610 Roller shutters/ curtains

Product range	Vision Roller Shutters

Spesifikasjonsdata - Rulleporter

Klassifiseringsdata
Opening sizes	12000 x 6000 mm. Veiledning for spesifikasjonsvalg: Available up to 12000 x 6000 mm (w x h). Veiledning fra produsent Width (maximum): Electric, GfA: 12 000 mm. Electric, NRG: Aluminium housing: 6000 mm; Steel housing: 12 000 mm. Manual: 3000 mm. Enclosure size (internal face fix): Dependent on height. - Electric, GfA: <2200 mm: 305 mm. 2200–3650 mm: 355 mm. 3650–4600 mm: 400 mm. 4600–6000 mm: 500 mm. - Electric, NRG: <2200 mm: 305 mm. 2200–3650 mm: 355–360 mm. 3650–4600 mm: 400 mm (steel only). - Manual: <2200 mm: 305 mm. 2200–3000 mm: 355 mm.
Arrangement	Vertical, external face fix. Vertical, internal face fix. Vertical, reveal fix.
Shutter curtain.	-
Lath material	Single skin curved steel, 76 mm in height. 0.7, 0.9 or 1.2 mm wall thickness, dependent on overall width. Bottom slat: Steel with brush and rubber weather seals.
Finish and colour	Galvanized. Veiledning for spesifikasjonsvalg: Standard. Plastisol coated, BS. Veiledning for spesifikasjonsvalg: Insert colour requirement. Plastisol coated, RAL. Veiledning for spesifikasjonsvalg: Insert colour requirement. Polyester powder coated, BS. Veiledning for spesifikasjonsvalg: Insert colour requirement. Polyester powder coated, RAL. Veiledning for spesifikasjonsvalg: Insert colour requirement.
Frame and guides	-
Material	Steel. Veiledning for spesifikasjonsvalg: Standard.
Finish	Galvanized. Veiledning for spesifikasjonsvalg: Standard. Polyester powder coated, BS. Veiledning for spesifikasjonsvalg: Insert colour requirement. Polyester powder coated, RAL. Veiledning for spesifikasjonsvalg: Insert colour requirement.
Operation	-
Mode	Electric, GfA three phase motor with push button control. Electric, NRG Economy tubular motor with internal rocker or external key switch. Manual, spring and lock.
Accessories	None. Crank handle. Manual override facility. Polycarbonate infills.
Guide channels depth	50 mm. 65 mm. 75 mm. 100 mm.
Vekt	8.3—14.2 kg. Veiledning for spesifikasjonsvalg: 8.3 kg (0.7 mm thickness). 10.6 kg (0.9 mm thickness). 14.2 kg (1.2 mm thickness).
Guide channels	Galvanized steel with brush weather seal.
Enclosure	Galvanized steel casing & end plates.
Bredde	12000 mm. Veiledning fra produsent Curtain slate maximum width.
Area	29 m². Veiledning for spesifikasjonsvalg: Tubular. 49 m². Veiledning for spesifikasjonsvalg: Outboard. Veiledning fra produsent Curtain slat maximum area.
