i95 Steel Security Shutter

Name: i95 Steel Security Shutter
Brand: Roché Systems Ltd
SKU: cnbGkdPY3Fp7VHyrAvLKmi

Verifisert av produsent for 1 måned siden

Roché Systems Ltd

Double skinned insulated steel security roller shutter with 95 mm high slats.

Gå til:

BOS

03330347967 Nettside

Applikasjon

Suitable for commercial sites and industrial units that have a large aperture.

Beskrivelse

Double skinned insulated steel security roller shutter with 95 mm high slats, providing a high security solution popular in commercial and industrial door applications. Developed to span larger openings, the i95 offers superb thermal performance as well as high security. The shutter can span up to 7 m in width and an area up to 35 m².

Features and benefits:

Guide channel depth: 80 mm.

Generell informasjon

Overflatebehandling	Galvanized Plastisol Powder-coated
Materiale	Steel
Form	Rectangle
Lengde	Bespoke
Bredde	Bespoke
Høyde	Bespoke
Garantibeskrivelse	One year

Uniclass	Pr_30_59_84_73 RulleporterPrimær
CAWS	L20/60 Doors L20/610 Roller shutters/ curtains

Product range	Extruded Roller Shutters

Spesifikasjonsdata - Rulleporter

Klassifiseringsdata
Opening sizes	7000 x 5000 mm. Veiledning for spesifikasjonsvalg: Available up to 7000 x 5000 mm (w x h). Veiledning fra produsent Enclosure size (internal face fix): Dependent on height. <3000 mm: 400 mm. 3000–4000 mm: 450 mm. 4000–5000 mm: 500 mm.
Arrangement	Vertical, external face fix. Vertical, internal face fix. Vertical, reveal fix.
Shutter curtain.	-
Lath material	Double skinned steel with polyurethane foam insulating core, 95 mm in height. Bottom slat: Polyester powder coated aluminium with weather seal.
Profile	- Veiledning fra produsent 95 mm.
Finish and colour	Galvanized. Veiledning for spesifikasjonsvalg: Standard. Polyester powder coated, BS. Veiledning for spesifikasjonsvalg: Insert colour requirement. Polyester powder coated, RAL. Veiledning for spesifikasjonsvalg: Insert colour requirement.
Frame and guides	-
Material	Enclosure: Roll formed steel with end plates. Guide channels: 85 mm deep steel with brush seals.
Finish	Galvanized. Veiledning for spesifikasjonsvalg: Standard. Polyester powder coated, BS. Veiledning for spesifikasjonsvalg: Insert colour requirement. Polyester powder coated, RAL. Veiledning for spesifikasjonsvalg: Insert colour requirement.
Operation	-
Mode	GfA three phase motor with push button control. NRG Economy tubular motor with internal rocker or external key switch. Veiledning fra produsent Numerous control option variants such as group, remote or mobile phone activation are available.
Control	Push button. Key switch.
Accessories	None. Crank handle. Manual override facility.
Vekt	12 kg/m².
Guide channel depth	80 mm.
