i100 Elite SR3 Steel Security Shutter

Name: i100 Elite SR3 Steel Security Shutter
Brand: Roché Systems Ltd
SKU: nCozQQ3vsgXzrjEq3D1w5v

Verifisert av produsent for 1 måned siden

Roché Systems Ltd

Produktsertifiseringer:

Secured By Design
Sertifikattype
LPCB Certification
Sertifikattype

LPCB SR3 insurance approved steel security roller shutter with 81 mm high slats.

Gå til:

BOS

03330347967 Nettside

Applikasjon

Suitable for high security commercial sites where burglary resistance is a priority.

Beskrivelse

LPCB SR3 insurance approved double skinned steel security roller shutter with 81 mm high slats.

Features and benefits:

Tested by the Loss Prevention Certification Board (LPCB) to LPS 1175 (7.0) SR3 and awarded insurance approved 'Secured by Design' status.
Galvanized steel bottom rail with rubber weather seal.
Span up to 7 m in width and an area up to 35 m² (outboard motor required).
Bullet locking system fixed to each guide channel.
Suitable for internal face fix only.

Generell informasjon

Farge	- Produsentveiledning Galvanized finish as standard. Option to powder coat any RAL / BS colour (surcharge applies).
Overflatebehandling	Galvanized Plastisol Powder-coated
Materiale	Steel
Form	Rectangle
Lengde	Bespoke
Bredde	Bespoke
Høyde	Bespoke
Garantibeskrivelse	One year

Uniclass	Pr_30_59_84_73 RulleporterPrimær
CAWS	L20/60 Doors L20/610 Roller shutters/ curtains

Product range	High Security Steel Shutters

Spesifikasjonsdata - Rulleporter

Klassifiseringsdata
Opening sizes	Veiledning for spesifikasjonsvalg: Available up to 7000 x 5000 mm (w x h). 10 m² (tubular) or 35 m² (outboard). Consult manufacturer for details and insert requirements. Veiledning fra produsent Enclosure size (internal face fix): Dependent on height. <2600 mm: 400 mm. 2600–3500 mm: 450 mm. 3600–5000 mm: 600 mm.
Arrangement	Vertical, external face fix. Vertical, internal face fix. Vertical, reveal fix.
Shutter curtain.	-
Lath material	27 mm thick flat double skinned steel, 100 mm in height. Bottom slat: Steel with brush weather seals.
Profile	Double skin. Double skin with insulated core.
Finish and colour	Galvanized. Veiledning for spesifikasjonsvalg: Standard. Plastisol coated, BS. Veiledning for spesifikasjonsvalg: Insert colour requirement. Plastisol coated, RAL. Veiledning for spesifikasjonsvalg: Insert colour requirement. Polyester powder coated, BS. Veiledning for spesifikasjonsvalg: Insert colour requirement. Polyester powder coated, RAL. Veiledning for spesifikasjonsvalg: Insert colour requirement.
Frame and guides	-
Material	Enclosure: Roll formed steel with end plates. Guide channels: 85 mm deep steel.
Finish	Galvanized. Veiledning for spesifikasjonsvalg: Standard. Polyester powder coated, BS. Veiledning for spesifikasjonsvalg: Insert colour requirement. Polyester powder coated, RAL. Veiledning for spesifikasjonsvalg: Insert colour requirement.
Colour	- Veiledning fra produsent Galvanized finish as standard. Option to powder coat any RAL / BS colour (surcharge applies). Insert requirements.
Operation	-
Mode	GfA three phase motor with push button control. NRG Economy tubular motor with internal rocker or external key switch. Veiledning fra produsent Numerous control option variants such as group, remote or mobile phone activation are available.
Control	Push button. Key switch.
Accessories	None. Crank handle. Manual override facility.
Guide channel depth	85 mm.
Vekt	37 kg/m².
