FS240 Fire Shutter

Name: FS240 Fire Shutter
Brand: Roché Systems Ltd
SKU: s58YvmW9eZFYB4gDnkXYPD

Verifisert av produsent for 1 måned siden

Roché Systems Ltd

Produktsertifiseringer:

Warringtonfire
Sertifikattype

Exova Warringtonfire approved single skin steel roller shutter providing 240 minutes' fire protection.

Gå til:

BOS

03330347967 Nettside

Applikasjon

Suitable for commercial offices, schools and hospitals

Beskrivelse

Fire rated single skin steel roller shutter with 76 mm high slats. FS fire shutter has been successfully tested at Exova Warringtonfire under BS EN 1634-1 test conditions and assessed to BS EN 476-22. The optional interface panel connects the shutter to a fire alarm system and the event of fire detection, the shutter automatically descends in a controlled manner to protect adjacent areas.

The shutter can span up to 12 m in width and an area up to 50 m².

Features and benefits:

Tested at Exova Warringtonfire under BS EN 1634-1 test conditions and compliant with BS EN 16034:2014.
Available up to up to 12 m in width and covers an area up to 50 m².
Optional interface panel connects the shutter to a fire alarm system and in the event of fire detection automatically descends.
Fire rated single skin steel roller shutter with 76 mm high slats providing 4 hours fire protection.

Generell informasjon

Overflatebehandling	Galvanized Plastisol Powder-coated
Materiale	Steel
Lengde	Bespoke
Bredde	Bespoke
Høyde	Bespoke
Garantibeskrivelse	One year

Uniclass	Pr_30_59_84_73 RulleporterPrimær
CAWS	L20/60 Doors L20/610 Roller shutters/ curtains

Product range	Fire Protection

Spesifikasjonsdata - Rulleporter

Klassifiseringsdata
Standard	To BS EN 16034:2014 and BS EN 1634-1.
Opening sizes	12 000 x 4750 mm. Veiledning for spesifikasjonsvalg: Available up to 12000 x 4750 mm (w x h). Veiledning fra produsent Enclosure size (internal face fix): Dependent on height. Up to 2500 mm: 305 mm. Up to 4000 mm: 355 mm. Up to 6000 mm: 400 mm.
Arrangement	Vertical, external face fix. Vertical, internal face fix. Vertical, reveal fix.
Shutter curtain.	-
Lath material	Single skin curved steel, 76 mm in height. 0.7, 0.9 or 1.2 mm wall thickness, dependent on overall width. Bottom slat: T-shaped steel.
Finish and colour	Galvanized. Veiledning for spesifikasjonsvalg: Standard. Plastisol coated, BS. Veiledning for spesifikasjonsvalg: Insert colour requirement. Plastisol coated, RAL. Veiledning for spesifikasjonsvalg: Insert colour requirement. Polyester powder coated, BS. Veiledning for spesifikasjonsvalg: Insert colour requirement. Polyester powder coated, RAL. Veiledning for spesifikasjonsvalg: Insert colour requirement.
Frame and guides	-
Material	Enclosure: Roll-formed steel housing and end plates. A barrel support frame at the centre of the housing may be required in some applications. Guide channels: Steel, bolted to fixing angles or steel box sections dependent on the application.
Finish	Galvanized. Veiledning for spesifikasjonsvalg: Standard. Polyester powder coated, BS. Veiledning for spesifikasjonsvalg: Insert colour requirement. Polyester powder coated, RAL. Veiledning for spesifikasjonsvalg: Insert colour requirement.
Operation	-
Mode	GfA three phase motor with push button control. NRG Economy tubular motor with internal rocker or external key switch. Veiledning fra produsent Numerous control option variants such as group, remote or mobile phone activation are available.
Accessories	None. Crank handle. Manual override facility. Interface panel.
Brannmotstand	Four hours.
Vekt	9–16 kg/m².
