Eurolook Transparent Security Shutter

Name: Eurolook Transparent Security Shutter
Brand: Roché Systems Ltd
SKU: joK1PSYy1oWBhCeTyWCaNM

Verifisert av produsent for 1 måned siden

Transparent security roller shutter with polycarbonate links.

Gå til:

BOS

Applikasjon

Suited to shops, banks and museums, where both high security and transparency are essential.

The Eurolook shutter is transparent and offers a maximum surface area of up to 50m² when mounted externally and 72m² when mounted internally.

Features and benefits:

Synthetic links of polycarbonate built in a brick formation as standard, enabling 83% transparency and 92% daylight transmission.
Extruded aluminium guides with a PVC weather seal.
Tested by SKG to ENV 1627-16390 standard with Class 3 security rating. Fire tested to BS 476:Part 7 (1997), Class 1 rating.

Uniclass	Pr_30_59_84_73 RulleporterPrimær
CAWS	L20/60 Doors L20/610 Roller shutters/ curtains

Product range	Vision Roller Shutters

Klassifiseringsdata
Opening sizes	12000 mm. Veiledning for spesifikasjonsvalg: 29m² (tubular motor), 72m² (outboard motor, internal fit) or 50m² (outboard motor, external fit). Veiledning fra produsent Plate size (internal face fix): Dependent on height. <3000 mm: 305 mm. 3000–3800 mm: 355 mm. 3800–5000 mm: 400 mm.
Arrangement	Vertical, external face fix. Vertical, internal face fix. Vertical, reveal fix.
Shutter curtain.	-
Lath material	17 mm thick aluminium with polycarbonate links, 85 mm in height.
Profile	- Veiledning fra produsent 85 mm.
Finish and colour	Transparent. Veiledning for spesifikasjonsvalg: Frosted or ventilated options available.
Frame and guides	-
Material	Guide channels: Extruded aluminium. Bottom slat: Extruded aluminium with EPDM weather seal.
Finish	Mill finish.
Colour	- Veiledning fra produsent Any RAL or BS standard colour available. Consult manufacturer and insert requirement.
Operation	-
Mode	NRG Econom tubular motor with internal rocker or external key switch as standard. Numerous control option variants such as group, remote or mobile phone activation are available.
Control	Push button. Key switch.
Accessories	None. Crank handle. Manual override facility.
Guide channel depth	80 mm. 115 mm.
Brannmotstand	To BS 476-7: Class 1.
