A1400 AIRSLIDE TK35 Automatic Sliding Door system - Sliding Door with Integrated Air Curtain

Name: A1400 AIRSLIDE TK35 Automatic Sliding Door system - Sliding Door with Integrated Air Curtain
Brand: FAAC Entrance Solutions UK
SKU: c7BsGqYtqbVNTN6sZwbRfm

Verifisert av produsent for 1 måned siden

Single - FAAC A1400 AIR 140 mm sliding door operator

FAAC Entrance Solutions UK

Produktsertifiseringer:

ADSA
Sertifikattype
UKAS
Sertifikattype

FAAC TK35 sliding door system with integrated air curtain and sliding door operator. For single door leaf and bi-parting double door leaves.

Gå til:

BOS

+44 (0)333 006 3443 Nettside

Applikasjon

Automatic sliding single or double door with integrated air curtain.

Beskrivelse

FAAC TK35 sliding door system with integrated air curtain and sliding door operator. For single door leaf or bi-parting double door leaves.

The unique AIRSLIDE system combines the automatic opening and air curtain system into a single unit, with unobtrusive aesthetic and functional advantages.

Features and benefits:

Available as a single door and double door system and part of a range of A1400 door operators.
Opening width: 950–1500 mm (single); 1200–2400 mm (double).
Supports door leaf up to 250 kg each (single) and up to 180 kg each (double).
System including normal installation to comply with BS 7036-0:2014 and BS EN 16005:2012.
Monitored emergency escape opening and threshold presence detection safety system, with 24 V d.c. E1/2SL monitored battery pack.
Exclusive intelligent energy saving function eliminates cross traffic opening, optimizing opening widths and hold open times.
To permit safe passage between closing doors, the doors go into reverse mode if an obstruction is detected, and then start moving again slowly to check if the obstruction has cleared.
Automatic adjustments: Determination of opening and closing positions. Selection of ideal speed, acceleration and deceleration.
Protection sensor monitoring.
Standard one year warranty (can be extended subject to quotation).

Manufacturer’s Declaration of Conformity

Tested to: EN 60335-1, EN 60335-2, EN 61000-6-2, EN 61000-6-3, EN ISO 13849-1, EN ISO 13849-2, EN ISO 12100 and EN 16005.

Generell informasjon

Farge	Silver Bronze Other Clear
Overflatebehandling	Anodized Powder-coated
Materiale	Glass
Form	Rectangle
Bredde	Bespoke
Høyde	Bespoke
Garantibeskrivelse	One year

Uniclass	Pr_30_59_24_80 Skyvedør- og skilleveggsettPrimær
CAWS	L20/490 Automatic doors

Spesifikasjonsdata - Skyvedør- og skilleveggsett

Klassifiseringsdata
Performance	Internal. External.
Arrangement	Top hung single door, left-hand opening. Top hung single door, right-hand opening.
Track system	FAAC A1400 AIR 140 mm sliding door operator (top track). Veiledning fra produsent With unique Energy Saving function providing automated operation. See below for additional track properties including finish options.
Door leaves	-
Construction	30 mm narrow door stiles; 10.8 mm clear laminated safety glass. 30 mm narrow door stiles; 24 mm double glazed unit with clear laminated safety glass. 60 mm wide door stiles; 10.8 mm clear laminated safety glass. 60 mm wide door stiles; 24 mm double glazed unit with clear laminated safety glass.
Finish and colour	Silver anodized. Bronze anodized. FAAC powder coat finish, RAL. Veiledning for spesifikasjonsvalg: Consult manufacturer for options and insert requirements.
Operation	Combined uni-directional and threshold presence detection entry/exit activator. Elbow push pads for entry/exit. Access control for entry and elbow push pad for exit. Contactless activation for entry/exit.
Accessories	None. Morning entry switch. Anti-panic breakout system APN. Veiledning fra produsent See also Locking mechanism and Activation for further options.
Dimensjoner	Veiledning for spesifikasjonsvalg: Insert requirements, subject to maximum door leaf weight of 200 kg: Opening width: 950–1500 mm. Height - either: Door height, operator wall mounted (1900–2500 mm) OR Overall height, operator beam mounted (2185–2500 mm).
Mode of operation	Digital FAAC SDK EVO multi-mode selector and configurator tool. Digital FAAC LK EVO with LED diagnostic and six-mode selector. Illuminated key switch FAAC EVO with five-mode selector.
Door protection	Finger protection - flush glazed externally and internally. Finger protection - flush glazed externally only.
Safety	Sidelight - monitored presence detection. Sidelight - full-height pivoted pocket screen.
Additional requirements	Sidelights, flush glazed externally, one panel. Sidelights, flush glazed externally and internally, one panel. Sidelights, flush glazed externally, two panels. Sidelights, flush glazed externally and internally, two panels. Overlight, flush glazed externally, one panel. Overlight, flush glazed externally and internally, one panel. Overlight, flush glazed externally, two panels. Overlight, flush glazed externally and internally, two panels. Not required. Veiledning fra produsent Select multiple options as required.
Lock	Mechanical single hook bolt lock. Mechanical three-point hook bolt lock. Mechanical two-point espagnolette lock. Veiledning fra produsent See also Cylinder and Locking mechanism.
Cylinder	One single Euro profile cylinder, keyed both sides. One single Euro profile cylinder, key with thumbturn. One double Euro profile cylinder, keyed both sides. One double Euro profile cylinder, key with thumbturn. Not required. Veiledning fra produsent See also Lock and Locking mechanism.
Locking mechanism	Fail safe (electric). Fail secure (electric). Bi-stable (electric). Not required. Veiledning fra produsent See also Cylinder and Lock.
Track finish	To match door. Silver anodized. Bronze anodized. FAAC powder coat finish, RAL. Veiledning for spesifikasjonsvalg: Consult manufacturer for options and insert requirements.
Standard	Door operator tested to EN 60335-1, EN 60335-2, EN 61000-6-2, EN 61000-6-3, EN ISO 13849-1, EN ISO 13849-2, EN ISO 12100 and EN 16005.
Threshold	Ramped. Level. Not required.
Fiksing	FAAC beam mounted. Wall mounted, beam by others. Veiledning for spesifikasjonsvalg: Insert details.
Control system	Manufacturer's standard. Veiledning for spesifikasjonsvalg: Monitored emergency escape opening and threshold presence detection safety system, with 24 V d.c. E1/2SL Monitored battery pack. Unique intelligent energy saving function eliminates cross traffic opening, optimizing opening widths and hold open times. To permit safe passage between closing doors, the doors go into reverse mode if an obstruction is detected, and then start moving again slowly to check if the obstruction has cleared. Automatic adjustments: Determination of opening and closing positions. Selection of ideal speed, acceleration and deceleration. Protection sensor monitoring. Switch-mode power supply to allow installation and commissioning between 110–240 V. Veiledning fra produsent See also: Activation: See Operation for options. Morning entry switch: See Accessories for options. Sidelight safety: See Safety for options. Operation mode selector: See Mode of operation for options.
Integral accessories	AIRSLIDE air curtain. Veiledning for spesifikasjonsvalg: The unique AIRSLIDE system combines the automatic opening and air curtain system into a single unit, with unobtrusive aesthetic and functional advantages. Electric fan unit concealed within an extruded aluminum cover, with the air intake grill in stainless steel. Electric board E1AS with four programmable speed levels. CANBUS connection for controlling the speed of the fans via a SDK evo functions keypad. Can drive up to two electric fan units. USB port for firmware updates. Power supply: 220–240 V. Maximum power consumption: 160 W single motor and 330 W dual motor. Electric motor: A synchronous single-phase motor. Motor rotation speed: 2850 rpm. Fan length: 360 to 500 mm. Dimensions: Depth 182 mm (depth) x 252 mm (height). Air speed output: 15.3 to 4.2 m/s. Airflow: 1250 m³/h. Noise level: 49.5 to 57.5 dB. Operating temperature: -20 to +55°C. Automation protection rating: IP23.
