Slimline Double Glazed Edge Symmetry Door

Name: Slimline Double Glazed Edge Symmetry Door
Brand: Optima
SKU: moue1FHrYxPxYVfNxgYuZq

Verified by manufacturer 18 days ago

Optima

Product certifications:

EPD
Certificate type

Slimline double glazed doors from the Edge Symmetry range feature a minimalist 30 mm stile. This slimline double glazed door offers 41dB Rw acoustic performance for premium glass partitions.

Jump to:

+44 (0)1494 492725 Website

Application

Slimline double glazed doors are ideal for high-end office fit-outs requiring a minimalist aesthetic. These slimline double glazed doors provide acoustic privacy with a symmetric profile.

Description

This slimline double glazed door is an aluminium framed acoustic doorset. The slimline double glazed door can be hinged or pivoted and integrates with Revolution 100 systems.

Features and benefits:

High acoustic performance: 41 dB (Rw).
Can be hinged or pivoted.
Slim 30 mm standard width stile.

General information

Color	Black White Silver Other
Finish	Anodized Grained Polished Powder-coated
Material	Glass Aluminium
Length	Bespoke
Width	Bespoke
Height	Bespoke
Warranty description	Ten year Guidance for specification option: See Warranty Policy literature for more information.

Uniclass	Pr_30_59_24_02 Aluminium doorsetsPrimary
CAWS	L20/480 Doorsets L20/55 Doorsets

Product range	Door Leaves Edge Aluminium Framed Glass Door

Specification data - Aluminium doorsets

Classification data
Doorset size	- Manufacturer guidance Single leaf size: 990 mm. Frame size: 1104 mm.
Frame	-
Material	Microflush D665 aluminium door frame.
Finish	-
Coating	Anodized. Guidance for specification option: 25 microns thickness. Grained, brightened and protective anodized. Polished, brightened and protective anodized. Powder-coated, RAL. Guidance for specification option: Insert requirement; contact manufacturer for more information. Powder-coated, RAL 9006 Silver. Guidance for specification option: 50 microns, 30% gloss (nominal). Powder-coated, RAL 9010 White. Guidance for specification option: 50 microns, 30% gloss (nominal).
Door leaf	-
Material	Glass.
Glazing	-
Type	6 mm heat-soaked toughened glass and 8 mm heat-soaked toughened glass (to BS EN 14179).
Manifestation	Guidance for specification option: Insert requirements.
Operation	Hinges. Pivots.
Locking	Dead lock. Latch. Sash lock.
Ironmongery	Guidance for specification option: Insert requirements from Optima standard ironmongery suite.

Sustainability data

Contains Red List materials	Yes
Country of product manufacture	United Kingdom
Manufacturing plant location	Mill Rd, Radstock BA3 5TX, UK
Material	Glass Aluminium
Carbon dioxide equivalent
Carbon dioxide equivalent, as defined in BS EN 15804 Certified
Stage Normalised unit (kg CO₂ eq/kg) Declared unit (kg CO₂ eq/m²) Stage:A1–A3 ('Production stage') Normalised unit : Declared unit : 64.5 Lower emissions Value guidance: A1-A3 See Environmental Product Declaration literature for detailed LCA data.
