PWF - Wood Finish Powder Coating

Name: PWF - Wood Finish Powder Coating
Brand: Powdertech (Corby) Ltd
SKU: rfuXYCSTdqyWzt9uwK6q3q

Verified by manufacturer 3 days ago

Powdertech (Corby) Ltd

Product certifications:

EPD
Certificate type
Warringtonfire
Certificate type
QA Certificate
Certificate type

Powdertech Wood Finish (PWF™) is formulated by Powdertech to match the natural variations in colour, grain density and grain pattern of wood. Wood Finish has been tested and approved to A2, s1-d0.

Jump to:

BOS

+44 (0)1536 400890 Website

Application

Wood finish is suitable for internal and external applications with both decorative and protective functions. When long spans are needed PWF can be used with aluminium or steel to produce a realistic and practical alternative.

Suitable for application onto galvanized steel, mild steel and aluminium.

Material design: Flat, folded, circular, formed, welded or fabricated.
Internal and external locations.
Architectural metalwork including façade, solar shading, spandrel panels, handrail etc.
General metalwork including signage, retail display, gates, posts.

Description

Powdertech Wood Finish (PWF™) was formulated by Powdertech to match the natural variations in colour, grain density and grain pattern of wood. Some of the finishes also have texture. Wood has an instinctive appeal as a building material, associated with the natural world and its warmth and texture.

Wood Finish | Powdertech Corby

Features and benefits:

Combines the strength and longevity of metal with the look of natural wood.
No pattern repeat - no two coated pieces ever look exactly the same.
Can be applied to most metallic substrates including aluminium, galvanized steel, cast metals and stainless steel.
Good weather resistance and colour stability.
Conforms to Reaction to Fire classification A2,s1-d0
Low maintenance - unlike wood.
Adapts to curved surfaces such as columns and posts.
Can be cut and drilled for fabrication.
There are 35 standard colours in smooth or texture finishes.
PWF Roughwood introduces the textured feel of wood.
Applied worldwide since 2000.
Resistance to boiling water, no blistering and no loss of adhesion.
Cylindrical mandrel bending, tested to ISO 1519, 5 mm mandrel, no cracking or detachment.

General information

Color	- Manufacturer guidance Full details at: Powdertech Wood Finish (PWF) \| Powdertech Corby
Finish	Smooth Textured Wood grain Woodgrain Manufacturer guidance Available as smooth or textured finish.
Material	Polyester Manufacturer guidance Powder coating material is a thin layer of pigmented polyester applied to a base metal.
Shape	Formless
Warranty description	25 year Guidance for specification option: For C2 and C3 environments: 25-year warranty for gloss, colour and adhesion. For C4, C5I and C5M environments: Guarantees are conditional on project location, environmental conditions and pre-contract approval.

Uniclass	Pr_35_31_68_66 Powder coatingsPrimary
CAWS	N91/120 Bespoke signage system N91/580 External sign R10/13 Combined fascia, soffit and gutter H11/830 Powder-coating H20/155 Sheet cladding (attached to timber battens) Z31/120 Powder-coating materials L10/51 Glazed screen systems L10/460 Rooflights L10/550 Glazed metal screens H10/115 Patent glazing L30/55 Proprietary balustrades L30/50 Purpose-made balustrades L10/45 Rooflights H92/830 Powder coating H43/120 Metal insulating sandwich panel R10/321 Combined fascia, soffit and gutter Q50/130 Gate Q50/120 Steel gate N91/580 External sign N91/120 Bespoke signage system L35/420 Carbon steel components L35/410 Aluminium components L30/560 Proprietary balustrades L30/550 Purpose-made balustrades H31/120 Metal profiled sheet self-supporting cladding/ roof covering H92/120 Rainscreen cladding H13/115 Structural glass assembly H11/145 Integrated access equipment H11/140 Louvres H11/130 Sun screens H11/110 Curtain walling H10/10 Patent glazing H20/10 Sheet cladding L10/54 Louvres H20/150 Sheet cladding (attached to metal support systems) H92/130 Major non-standard components L10/560 Glazed screen systems L10/650 Metal louvres

SKU Code	Wood effect finish

Specification data - Powder coatings

Classification data
Standard	To BS EN 12206-1 and ISO 13438.
Powder formulation	Durable.
Gloss level	20—70%. Guidance for specification option: At 60ᵒ.
Film thickness	>60 µm.
Adhesion	Rating 0. Guidance for specification option: Dry adhesion cross hatch (ISO 2409) Rating 0, no coating detachment, wet adhesion (ISO 2409) after 1 hour pressure cooker rating 0, no detachment.
Accelerated weathering	1000 hours no significant change in colour, >50% retained gloss. Guidance for specification option: To ISO 16474-2:2013.
Sulphur dioxide resistance	24 cycles no infiltration. Guidance for specification option: Exceeding 1 mm from the scribe, no change in colour or blistering in excess of 2(S2) to ISO 4628-2.
Constant humidity resistance	1000 hours. Guidance for specification option: To ISO 6272-2, <1mm scribe creep. No blistering in excess of 2(S2) to ISO 4628-2.
Impact resistance	No cracking or detachment. Guidance for specification option: Tested to ISO 6272-2, reverse Impact test.
Erichsen cupping	No cracking or detachment. Guidance for specification option: Tested to ISO 1520, minimum 5 mm indent.
Permeability	No blistering or coating detachment.
Scratch resistance	E2 Pass. Guidance for specification option: To BS 3900.
Pre-treatment	Aluminium: Titanium-zirconium (TiZr) non-chrome six-stage pre-treatment. Galvanized steel: Silane (oxsilan) non-chrome eight-stage pre-treatment. Not required/ other. Guidance for specification option: Consult manufacturer for details for surfaces other than aluminium or galvanized steel.
Application method	Corona discharge system. Guidance for specification option: Powder application.
Fire rating (to BS EN 13501)	A2-s1, d0.

Sustainability data

Material	Polyester Manufacturer guidance Powder coating material is a thin layer of pigmented polyester applied to a base metal.
Carbon dioxide equivalent
Carbon dioxide equivalent, as defined in BS EN 15804 Certified
Stage Normalised unit Declared unit Stage:A1–A3 ('Production stage') Normalised unit : Declared unit : - Manufacturer guidance LCA: A1-A3. 3.29 to 5.06 Kg CO2 eq/kg. Contact Powdertech for more information.
Recyclability	Does not affect the recyclability of the substrate material
Recycled content As defined in clause 7.8 of BS EN ISO 14021	0 %
