Pitchglaze Conservation Roof Window

Name: Pitchglaze Conservation Roof Window
Brand: Glazing Vision Ltd
SKU: 7ndXXPja8FDUmw52pQNdFu

Verified by manufacturer 1 month ago

Glazing Vision Ltd

Product certifications:

BSI Kitemark
Certificate type
Qualicoat approval
Certificate type

Heritage style pitched low profile roof window with aluminium frame, designed for conservation areas and listed buildings.

Jump to:

BOS

+44 (0)1379 658300 Website

Application

Suitable for pitched roof applications, ranging from 15° to 85°. Specifically designed for use within conservation areas, listed buildings, Areas of Outstanding Natural Beauty and properties subject to Article 4 Direction.

May be used for a range of projects, including:

Period refurbishments.
Barn conversions.
Industrial heritage schemes.

Description

The Glazing Vision Pitchglaze Conservation Roof Window is a heritage style fixed in-pane roof window with a low profile. It can be specified in larger formats in both portrait and landscape orientations.

The design replicates the appearance of traditional Victorian cast-iron roof glazing, utilising an aluminium frame, powder-coated in RAL 7015 slate grey as standard.

It incorporates integral mullion bars to accurately reflect the proportions and detailing of historic roof windows, enabling specifiers to achieve traditional visual character whilst meeting modern performance requirements.

Features and benefits:

UKCA and CE marked.
Excellent thermal performance and air tightness.
Robust and long-lasting.
Variety of optional extras, including special colour and easy clean coating available.

General information

Color	Grey Guidance for specification option: As standard. Other Guidance for specification option: Range of special colours available on request.
Finish	Powder-coated
Material	Aluminium Glass
Shape	Rectangle Square
Length	Bespoke Guidance for specification option: Minimum 300 mm, maximum 3000 mm.
Width	Bespoke Guidance for specification option: Minimum 300 mm, maximum 3000 mm.
Height	Bespoke
Warranty description	Two year

Uniclass	Pr_30_59_72_31 Framed rooflightsPrimary
CAWS	L10/45 Rooflights L10/460 Rooflights

Specification data - Framed rooflights

Classification data
Form	Rectangular. Square.
Size	- Manufacturer guidance Custom sizes: Length: 300–3000 mm. Width: 300–3000 mm.
Performance characteristics	-
Whole window U-value	- Manufacturer guidance Varies. Calculated based on configuration of individual products.
Frame	-
Material	Aluminium.
Finish	-
Coating	Polyester powder coating. Guidance for specification option: To the Qualicoat Standard.
Colour	RAL 7015, slate grey. Guidance for specification option: As standard. RAL, special order. Guidance for specification option: Consult manufacturer and insert requirements.
Glazing or infill	-
Type	- Manufacturer guidance Wide variety of glazing options available, e.g. laminated, annealed laminated, heat strengthened, and toughened. Consult manufacturer for details and insert requirements.
Construction	Double skin. Triple skin.
Coating	Easy clean coating. Guidance for specification option: Optional coating applied to the external face of the glass that facilitates water run-off. Helps the glass stay cleaner for longer and makes cleaning easier. Not required.
Operation	-
Type	Fixed.
Accessories	Not required. Flashing kit. Guidance for specification option: Optional kit containing all materials required to flash/ weather the product into the surrounding roofing.
Standard	To EN 14351-1.
Certification	UKCA and CE marked.
Area	0.09–4.10 m².
Roof pitch	15–85°.
Seals	Silicone, poly-butyl and EPDM rubber seals.
Security	Structural fixings.
